Sharp XR-32S-L Service Manual

XR-32S-L/XR-32X-L/PG-F212X-L
20
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
R928 VRS-TV1JD224FY AA J Resistor 220k 1/16W Metal Oxide
R929 VRS-TV1JD224FY AA J Resistor 220k 1/16W Metal Oxide
R930 VRS-TV1JD224FY AA J Resistor 220k 1/16W Metal Oxide
R931 VRS-TV1JD224FY AA J Resistor 220k 1/16W Metal Oxide
R932 VRS-TV1JD224FY AA J Resistor 220k 1/16W Metal Oxide
R933 VRS-TV1JD224FY AA J Resistor 220k 1/16W Metal Oxide
R934 VRS-TV1JD153FY AA J Resistor 15k 1/16W Metal Oxide
R935 VRS-TV1JD153FY AA J Resistor 15k 1/16W Metal Oxide
R936 VRS-TV1JD103JY AA J Resistor 10k 1/16W Metal Oxide
R937 VRS-TQ2BD102JY AA J Resistor 1k 1/8W Metal Oxide
R938 VRS-TV1JD100JY AA J Resistor 10 1/16W Metal Oxide
R940 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R941 VRS-TV1JD103JY AA J Resistor 10k 1/16W Metal Oxide
R942 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R943 VRS-TQ2EF102JY AA J Resistor 1k 1/4W Metal Oxide
R944 VRS-TV1JD223JY AA J Resistor 22k 1/16W Metal Oxide
R945 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R946 VRS-TV1JD103JY AA J Resistor 10k 1/16W Metal Oxide
R947 VRS-TQ2EF470JY AA J Resistor 47 1/4W Metal Oxide
R948 VRS-TQ2EF470JY AA J Resistor 47 1/4W Metal Oxide
R950 VRS-TW2HPR33JY AA J Resistor 0.33 1/2W Metal Oxide
R951 VRS-TW2HPR33JY AA J Resistor 0.33 1/2W Metal Oxide
R952 VRS-TW2HPR33JY AA J Resistor 0.33 1/2W Metal Oxide
R953 VRS-TW2HPR33JY AA J Resistor 0.33 1/2W Metal Oxide
R954 VRS-TW2HPR33JY AA J Resistor 0.33 1/2W Metal Oxide
R955 VRS-TW2HPR33JY AA J Resistor 0.33 1/2W Metal Oxide
R956 VRS-TW2HF273JY AB J Resistor 27k 1/2W Metal Oxide
R957 VRS-TW2HF273JY AB J Resistor 27k 1/2W Metal Oxide
R958 VRS-TW2HF273JY AB J Resistor 27k 1/2W Metal Oxide
R959 VRS-TW2HF273JY AB J Resistor 27k 1/2W Metal Oxide
RDA701 PRDARA459WJFW AG N J Heat Sink
RDA702 PRDARA441WJFW AK J Heat Sink
RDA901 PRDARA441WJFW AK J Heat Sink
RDA902 PRDARA727WJFW AK N J
Heat Sink
!
RY702 RRLYDA008WJZZ AG J Relay
!
T704 RTRNWA304WJZZ AE N J Transformer
T901 RTRNZA102WJZZ AH J Transformer
T902 RTRNWA188WJZZ AK J Transformer
TH901 RH-HXA020WJZZ AK J Thermistor PTFM04BB222Q2N34B0
!
VA702 RH-VXA195WJZZ AL J Varistor TNR10SV471K318
N LX-BZ3049GEFN AB J Screw, x9
N LX-BZA044WJFU AA J Screw, x2
N QCNW-F717WJQZ AS J Connecting Cord
N XBSSN30P06000 AA J Screw, x2
[5] DUNTKE395WEF3 (BALLAST CONTROL Unit)
C7701 VCKYCY1EB683KY AB J Capacitor 0.068 25V Ceramic
C7702 RC-KZA114WJZZY AB J Capacitor 1 25V Ceramic
C7703 VCKYCY1CB224KY AB J Capacitor 0.22 16V Ceramic
C7705 VCKYCY1CB224KY AB J Capacitor 0.22 16V Ceramic
C7706 RC-KZA114WJZZY AB J Capacitor 1 25V Ceramic
C7707 VCKYTV1CB105KY AC J Capacitor 1 16V Ceramic
C7708 VCCCCY1HH471JY AA J Capacitor 470p 50V Ceramic
C7709 RC-KZA114WJZZY AB J Capacitor 1 25V Ceramic
C7710 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C7712 VCCCCY1HH221JY AA J Capacitor 220p 50V Ceramic
C7713 VCKYCY1CB224KY AB J Capacitor 0.22 16V Ceramic
C7714 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C7716 VCKYCY1CB104KY AB J Capacitor 0.1 16V Ceramic
C7717 VCKYCY1HB102KY AA J Capacitor 1000p 50V Ceramic
C7718 VCCCCY1HH102JY AB J Capacitor 1000p 50V Ceramic
C7719 VCKYCY1HB222KY AA J Capacitor 2200p 50V Ceramic
C7720 VCKYCY1CB104KY AB J Capacitor 0.1 16V Ceramic
C7722 VCKYTV1CB224KY AB J Capacitor 0.22 16V Ceramic
C7723 RC-KZA114WJZZY AB J Capacitor 1 25V Ceramic
C7724 VCKYCY1CF104ZY AA J Capacitor 0.1 16V Ceramic
C7729 VCKYCY1HB102KY AA J Capacitor 1000p 50V Ceramic
C7730 RC-KZA114WJZZY AB J Capacitor 1 25V Ceramic
C7731 VCKYCY1EB223KY AA J Capacitor 0.022 25V Ceramic
C7732 VCKYCY1HF104ZY AA J Capacitor 0.1 50V Ceramic
C7733 VCKYCY1HB102KY AA J Capacitor 1000p 50V Ceramic
C7734 VCKYTV1CB105KY AC J Capacitor 1 16V Ceramic
C7735 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C7736 VCKYCY1CF104ZY AA J Capacitor 0.1 16V Ceramic
C7737 VCKYCY1CB104KY AB J Capacitor 0.1 16V Ceramic
C7738 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C7739 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C7740 VCKYTV1CB105KY AC J Capacitor 1 16V Ceramic
C7741 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C7742 VCKYCY1HB102KY AA J
Capacitor 1000p 50V Ceramic
C7743 VCKYCY1HB102KY AA J Capacitor 1000p 50V Ceramic
C7744 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C7745 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C7746 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C7747 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
[4] DUNTKE392WEF3 (BALLAST POWER Unit)
