Sharp XR-32S-L Service Manual

XR-32S-L/XR-32X-L/PG-F212X-L
21
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
C7748 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C7749 VCKYTV1CB105KY AC J Capacitor 1 16V Ceramic
C7750 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C7751 VCKYCY1CF104ZY AA J Capacitor 0.1 16V Ceramic
C7752 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C7754 VCKYCY1EB223KY AA J Capacitor 0.022 25V Ceramic
C7756 VCKYCY1CB104KY AB J Capacitor 0.1 16V Ceramic
C7757 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C7758 VCKYTV1CB105KY AC J Capacitor 1 16V Ceramic
C7759 VCKYCY1HB222KY AA J Capacitor 2200p 50V Ceramic
C7761 VCCCCY1HH331JY AA J Capacitor 330p 50V Ceramic
C7762 RC-KZA110WJZZY AD J Capacitor 10 Electrolytic
C7764 VCCCCY1HH331JY AA J Capacitor 330p 50V Ceramic
C7765 VCCCCY1HH331JY AA J Capacitor 330p 50V Ceramic
C7766 VCCCCY1HH331JY AA J Capacitor 330p 50V Ceramic
C7767 VCCCCY1HH221JY AA J Capacitor 220p 50V Ceramic
D7702 VHDBAS316//-1Y AB J Diode BAS316,115
D7703 VHDBAS316//-1Y AB J Diode BAS316,115
D7704 VHDBAS316//-1Y AB J Diode BAS316,115
D7705 VHDBAS316//-1Y AB J Diode BAS316,115
D7706 RH-EX0259TAZZY AB J Diode PDZ5.6B,115
D7707 VHD1PS184++-1Y AB J Diode 1PS184,115
D7708 VHDBAS316//-1Y AB J Diode BAS316,115
D7709 VHDBAS316//-1Y AB J Diode BAS316,115
D7710 VHDBAS316//-1Y AB J Diode BAS316,115
!
D7714 RH-FXA005WJZZY AD J Diode PC123ZY8J00F
!
D7715 RH-FXA005WJZZY AD J Diode PC123ZY8J00F
!
D7717 RH-FXA012WJZZY AV J Diode TLP750(D4SHR-OT4,F)
FL7701 RFiLZA003WJPZY AD J Filter
IC7701 VHiM51995AF-1Y AM J IC M51995AFPCF0J
IC7702 VHiNJM2904V-1Y AF J IC NJM2904V-TE1
IC7703 VHiNJM2902V-1Y AD J IC NJM2902V(TE1)
IC7704 VHiTA78L05F-1Y AE J IC TA78L05F(TE12L,F)
IC7705 VHiBU4242G+-1Y AC J IC BU4242G-TR
IC7706 VHiNJM2901V-1Y AE J IC NJM2901V(TE1)
IC7707 RH-iXC630WJZZQ AX N J IC 86FS49BUG-7BJ7(JZ
P7701 QPLGN0664TAZZY AD J Plug 6Pin
Q7709 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q7710 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q7711 VS2SA1162Y/-1Y AB J Transistor 2SA1162-Y(TE85L,F)/(T5L,F,T)
R7701 VRS-CY1JF472JY AA J Resistor 4.7k 1/16W Metal Oxide
R7702 VRS-CY1JF101JY AA J Resistor 100 1/16W Metal Oxide
R7703 VRS-CY1JF182JY AA J Resistor 1.8k 1/16W Metal Oxide
R7706 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R7708 VRS-CY1JF562JY AA J Resistor 5.6k 1/16W Metal Oxide
R7709 VRS-TV1JD102JY AA J Resistor 1k 1/16W Metal Oxide
R7711 VRS-CY1JF333JY AA J Resistor 33k 1/16W Metal Oxide
R7712 VRS-CY1JF474JY AA J Resistor 470k 1/16W Metal Oxide
R7713 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R7714 VRS-CY1JF123JY AA J Resistor 12k 1/16W Metal Oxide
R7715 VRS-CY1JF333JY AA J Resistor 33k 1/16W Metal Oxide
R7718 VRS-CY1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R7719 VRS-CY1JF123JY AA J Resistor 12k 1/16W Metal Oxide
R7720 VRS-CY1JF333JY AA J Resistor 33k 1/16W Metal Oxide
R7721 VRS-CY1JF152JY AA J Resistor 1.5k 1/16W Metal Oxide
R7722 RVR-M4555CEZZY AC J Resistor Variable Resistor
R7723 VRS-CY1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R7724 VRS-CY1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R7725 VRS-CY1JF682JY AA J Resistor 6.8k 1/16W Metal Oxide
R7727 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R7728 VRS-CY1JF561DY AB J
Resistor 560 1/16W Metal Oxide
R7729 VRS-CY1JF222JY AA J Resistor 2.2k 1/16W Metal Oxide
R7730 VRS-CY1JF122JY AA J Resistor 1.2k 1/16W Metal Oxide
R7732 VRS-CY1JF101JY AA J Resistor 100 1/16W Metal Oxide
R7733 VRS-CY1JF472JY AA J Resistor 4.7k 1/16W Metal Oxide
R7734 VRS-CY1JF472DY AA J Resistor 4.7k 1/16W Metal Oxide
R7735 VRS-CY1JF222JY AA J Resistor 2.2k 1/16W Metal Oxide
R7736 VRS-TQ2BD4R7JY AA J Resistor 4.7 1/8W Metal Oxide
R7737 VRS-TQ2BD4R7JY AA J Resistor 4.7 1/8W Metal Oxide
R7738 VRS-CY1JF122JY AA J Resistor 1.2k 1/16W Metal Oxide
R7739 VRS-CY1JF151JY AA J Resistor 150 1/16W Metal Oxide
R7740 VRS-CY1JF152DY AA J Resistor 1.5k 1/16W Metal Oxide
R7741 VRS-CY1JF152DY AA J Resistor 1.5k 1/16W Metal Oxide
R7742 VRS-CY1JF152DY AA J Resistor 1.5k 1/16W Metal Oxide
R7743 VRS-CY1JF152DY AA J Resistor 1.5k 1/16W Metal Oxide
R7744 VRS-CY1JF152DY AA J Resistor 1.5k 1/16W Metal Oxide
R7745 VRS-CY1JF152DY AA J Resistor 1.5k 1/16W Metal Oxide
R7746 VRS-CY1JF152DY AA J Resistor 1.5k 1/16W Metal Oxide
R7747 VRS-CY1JF472DY AA J Resistor 4.7k 1/16W Metal Oxide
R7748 VRS-CY1JF472DY AA J Resistor 4.7k 1/16W Metal Oxide
R7749 VRS-CY1JF472DY AA J Resistor 4.7k 1/16W Metal Oxide
R7750 VRS-CY1JF472DY AA J Resistor 4.7k 1/16W Metal Oxide
R7751 VRS-CY1JF472DY AA J Resistor 4.7k 1/16W Metal Oxide
R7752 VRS-CY1JF472DY AA J Resistor 4.7k 1/16W Metal Oxide
R7753 VRS-CY1JF472DY AA J Resistor 4.7k 1/16W Metal Oxide
[5] DUNTKE395WEF3 (BALLAST CONTROL Unit)
