XR-32S-L/XR-32X-L/PG-F212X-L

XR32SL

Service Manual

OUTLINE AND CHANGED PARTS LIST

OUTLINE

This Service Manual covers the differences from XR-32S/XR-32X/PG-F212X. For other technical information, refer to the XR-32S/XR-32X/PG-F212X

(No. S18C8XR-32S/X) Service Manual.

CHANGED PARTS LIST

Ref No. Description XR-32S/XR-32X/PG-F212X XR-32S-L/XR-32X-L/PG-F212X-L Note

PRINTED WIRING BOARD ASSEMBLIES

MAIN Unit DUNTKE390FMF0/1/2 DUNTKE390FMG4/5/6 Some parts changed

DMD Unit DUNTKE391WEF0 ← No parts changed

BALLAST POWER Ass'y DSETUE392FMG1 DSETUE392FMG3 —

(with Ballast Control Unit)

BALLAST CONTROL Unit DUNTKE395WEF0/1 DUNTKE395WEF3 Some parts changed

R/C RECEIVER Unit DUNTKE396WEF0/1 DUNTKE396WEF3 No parts changed

PHOTO SENSOR Unit DUNTKE397WEF1 DUNTKE397WEF3 No parts changed

BALLAST POWER Unit DUNTKE392WEF0/1 DUNTKE392WEF3 Some parts changed

DUNTKE390FMG4/5/6 (MAIN Unit)

C3384 Capacitor No VCKYCY1CB104KY Add

C3385 Capacitor No VCKYCY1EF104ZY (PG-F212X-L) Add

C3826 Capacitor No RC-KZA110WJZZY Add

C3827 Capacitor No RC-KZA110WJZZY Add

FB3305 Ferrite Bead No RBLN-A042WJZZY (PG-F212X-L)

IC2232 IC RH-iXB742WJZZQ RH-iXC615WJZZQ Changed

IC2262 IC RH-iXC382WJZZQ (PG-F212X) RH-iXC783WJZZQ (PG-F212X-L) Changed

IC2262 IC RH-iXC383WJZZQ (XR-32X) RH-iXC781WJZZQ (XR-32X-L) Changed

IC2262 IC RH-iXC384WJZZQ (XR-32S) RH-iXC782WJZZQ (XR-32S-L) Changed

IC3051 IC RH-iXC386WJZZS (PG-F212X) RH-iXC386WJZZS (PG-F212X-L) Changed

IC3051 IC RH-iXC389WJZZS (XR-32X) RH-iXC389WJZZS (XR-32X-L) Changed

IC3358 IC No VHi7SB3157P-1Y (PG-F212X-L) Add

Q3325 Transistor No VS2SA1530AR-1Y (PG-F212X-L) Add

R1764 Resistor VRS-TW2HF1R0JY VRS-TW2ED000JY Changed

R1765 Resistor VRS-TW2HF1R0JY VRS-TW2ED000JY Changed

R3037 Resistor No VRS-CY1JF000JY Add

R3043 Resistor No VRS-CY1JF000JY (PG-F212X-L) Add

R3346 Resistor No VRS-CY1JF101JY (PG-F212X-L) Add

R3347 Resistor No VRS-CY1JF102JY (PG-F212X-L) Add

R3348 Resistor No VRS-CY1JF000JY (XR-32S-L/XR-32X-L) Add

R3404 Resistor VRS-CY1JF000JY No Delete

SC2801 Socket QSOCNA423WJPZ (XR-32X) QSOCZA061WJZZ (PG-F212X-L) Changed

SC2801 Socket QSOCZA061WJZZ (PG-F212X) QSOCNA423WJPZ (XR-32X-L) Changed

DUNTKE392WEF3 (BALLAST POWER Unit)

C711 Capacitor RC-EZA452WJZZ RC-EZB527WJZZ Changed

C728 Capacitor RC-EZA486WJZZ RC-EZB528WJZZ Changed

C740 Capacitor RC-EZB440WJZZ RC-EZB574WJZZ Changed

C751 Capacitor No RC-KZA215WJZZY Add

CN901 Connecting Cord QCNW-G638WJQZ QCNW-H946WJQZ Changed

D703 Diode VHDRB085T40-1 VHDSBT8006J-1 Changed

D716 Diode VHDRB085T90-1 VHDSBT8010J-1 Changed

D720 Diode RH-DXA074WJZZ VHDRD1006LS-1 Changed

D903 Diode VHDSF8L60UM-1 VHDRD1006LS-1 Changed

Q704 Transistor VS2SK3797++-1 VS2SK4087LS1E Changed

Q705 Transistor VS2SK3797++-1 VS2SK4087LS1E Changed

Q901 Transistor VS2SK3797++-1 VS2SK4087LS1E Changed

RDA902 Heat Sink PRDARA521WJFW PRDARA727WJFW Changed

DUNTKE395WEF3 (BALLAST CONTROL Unit)

C7735 Capacitor VCKYCY1EB223KY VCKYCY1HB103KY Changed

IC7707 IC RH-iXC122WJZZQ RH-iXC630WJZZQ Changed

R7765 Resistor No VRS-CY1JF101JY Add

R7766 Resistor VRS-CY1JF103JY No Delete
