Sharp XR-32X-L Service Manual

XR-32S-L/XR-32X-L/PG-F212X-L
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
N DUNTKE390FMG4 CX N J MAIN Unit (XR-32S-L)
N DUNTKE390FMG5 CX N J MAIN Unit (XR-32X-L)
N DUNTKE390FMG6 CY N J MAIN Unit (PG-F212X-L)
N DUNTKE391WEF0 BN N J DMD Unit (without the DMD chip)
N DSETUE392FMG3 N J BALLAST POWER Ass'y (with Ballast Control Unit)
N DUNTKE395WEF3 BH N J BALLAST CONTROL Unit
N DUNTKE396WEF3 AP N J R/C RECEIVER Unit
N DUNTKE397WEF3 AR N J PHOTO SENSOR Unit
N Not Available - N -
BALLAST POWER Unit (Order the BALLAST POWER Ass'y (DSETUE392FMG3) when
replacing ballast power unit (DUNTKE392WEF3).
[2] DUNTKE390FMG4/5/6 (MAIN Unit)
C1701 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C1702 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1703 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1704 VCEAPF1CW106MY AB J Capacitor 10 16V Electrolytic
C1705 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1709 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C1710 VCEAPF0JW226MY AB J Capacitor 22 6.3V Electrolytic
C1711 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1712 VCEAPF1CW336MY AD J Capacitor 33 16V Electrolytic
C1719 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C1722 RC-KZA114WJZZY AB J Capacitor 1 25V Ceramic
C1723 VCEAPF1CW336MY AD J Capacitor 33 16V Electrolytic
C1724 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1725 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C1726 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1727 VCEAPF1EW106MY AC J Capacitor 10 25V Electrolytic
C1728 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C1730 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1731 VCEAPF1EW106MY AC J Capacitor 10 25V Electrolytic
C1732 RC-KZA114WJZZY AB J Capacitor 1 25V Ceramic
C1733 VCEAPF1EW106MY AC J Capacitor 10 25V Electrolytic
C1734 RC-KZA114WJZZY AB J Capacitor 1 25V Ceramic
C1735 VCEAPF1EW106MY AC J Capacitor 10 25V Electrolytic
C1748 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1749 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C1750 VCEAPF1CW336MY AD J Capacitor 33 16V Electrolytic
C1751 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C1752 VCEAPF1EW106MY AC J Capacitor 10 25V Electrolytic
C1753 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C1754 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1755 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C1760 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1761 VCEAPF1CW336MY AD J Capacitor 33 16V Electrolytic
C1762 VCKYCY1EF104ZY AA J
Capacitor 0.1 25V Ceramic
C1763 VCEAPF1EW106MY AC J Capacitor 10 25V Electrolytic
C1764 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C1781 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C1785 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1795 VCEAPF1CW106MY AB J Capacitor 10 16V Electrolytic
C1796 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1797 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C1798 VCEAPF1CW336MY AD J Capacitor 33 16V Electrolytic
C2001 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C2002 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C2003 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C2004 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C2005 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C2006 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C2007 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C2008 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C2009 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C2010 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C2011 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C2012 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C2013 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C2014 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C2015 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C2016 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C2017 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C2018 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C2019 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C2020 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C2021 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C2022 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C2023 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C2024 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C2025 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C2026
VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C2027 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C2028 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C2029 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C2030 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C2031 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
