Sharp XR-32X-L Service Manual

XR-32S-L/XR-32X-L/PG-F212X-L
6
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
C3514 VCEAPF1HW105MY AB J Capacitor 1 50V Electrolytic (XR-32X-L/PG-F212X-L)
C3515 VCEAPF1CW106MY AB J Capacitor 10 16V Electrolytic (XR-32X-L/PG-F212X-L)
C3523 VCEAPF1CW106MY AB J Capacitor 10 16V Electrolytic (XR-32X-L/PG-F212X-L)
C3524 VCEAPF1CW106MY AB J Capacitor 10 16V Electrolytic (XR-32X-L/PG-F212X-L)
C3531 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C3533 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C3535 VCEAPF0JW107MY AC J Capacitor 100 6.3V Electrolytic
C3537 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C3538 VCEAPF0JW227MY AD J Capacitor 220 6.3V Electrolytic
C3539 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C3540 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C3541 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C3545 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C3552 VCEAPF1CW107MY AC J Capacitor 100 16V Electrolytic
C3553 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C3554 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C3555 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C3556 VCEAPF1EW106MY AC J Capacitor 10 25V Electrolytic
C3557 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C3561 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C3562 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C3563 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C3571 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C3572 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C3601 VCEAPF1CW226MY AB J Capacitor 22 16V Electrolytic
C3802 RC-KZA387WJZZY AF J Capacitor 22 10V Ceramic
C3803 RC-KZA387WJZZY AF J Capacitor 22 10V Ceramic
C3805 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C3806 VCAAPD1AJ686MY AE J Capacitor 68 10V Electrolytic
C3807 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C3808 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C3809 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C3811 VCKYTV1EB334KY AB J Capacitor 0.33 25V Ceramic
C3812 VCCCCY1HH471JY AA J
Capacitor 470p 50V Ceramic
C3813 VCKYCY1HB152KY AA J Capacitor 1500p 50V Ceramic
C3814 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C3815 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C3816 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C3817 VCAAPD1DJ476MY AF J Capacitor 47 20V Electrolytic
C3818 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C3819 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C3820 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C3821 VCKYTV1EB334KY AB J Capacitor 0.33 25V Ceramic
C3822 RC-KZA098WJZZY AD J Capacitor 10 25V Ceramic
C3824 RC-KZA098WJZZY AD J Capacitor 10 25V Ceramic
C3825 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C3826 RC-KZA110WJZZY AD J Capacitor 10 Electrolytic
C3827 RC-KZA110WJZZY AD J Capacitor 10 Electrolytic
C3828 VCKYTV1EB334KY AB J Capacitor 0.33 25V Ceramic
C3829 VCKYCY1CB224KY AB J Capacitor 0.22 16V Ceramic
C3830 RC-KZA098WJZZY AD J Capacitor 10 25V Ceramic
C3831 VCKYTV1EB334KY AB J Capacitor 0.33 25V Ceramic
C3832 VCKYCY1EB473KY AA J Capacitor 0.047 25V Ceramic
C3833 VCKYTV1EB334KY AB J Capacitor 0.33 25V Ceramic
C3834 VCKYCY1CB224KY AB J Capacitor 0.22 16V Ceramic
C3835 RC-KZA098WJZZY AD J Capacitor 10 25V Ceramic
C3836 RC-KZA098WJZZY AD J Capacitor 10 25V Ceramic
C3837 VCKYCY1HB102KY AA J Capacitor 1000p 50V Ceramic
C3838 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C3839 RC-KZA387WJZZY AF J Capacitor 22 10V Ceramic
C3840 VCKYCY1HB102KY AA J Capacitor 1000p 50V Ceramic
C3841 VCAAPD0JJ127MY AF J Capacitor 120 6.3V Electrolytic
C3843 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C3844 VCKYCY1HB102KY AA J Capacitor 1000p 50V Ceramic
C3845 VCCCCY1HH101JY AA J Capacitor 100p 50V Ceramic
C3847 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C3848 VCKYCY1HB102KY AA J Capacitor 1000p 50V Ceramic
C3849
VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
D1703 VHDBAS316//-1Y AB J Diode BAS316,115
D1704 VHDBAS316//-1Y AB J Diode BAS316,115
D1717 VHD1SS377L+-1Y AC J Diode 1SS377(TE85L,F)
D1718 VHD1SS377L+-1Y AC J Diode 1SS377(TE85L,F)
D1721 VHD1PS184++-1Y AB J Diode 1PS184,115
D1722 VHD1PS184++-1Y AB J Diode 1PS184,115
D1723 VHDRB551V30-1Y AC J Diode RB551V-30TE-17
D1724 VHDRB551V30-1Y AC J Diode RB551V-30TE-17
D1725 VHDRB551V30-1Y AC J Diode RB551V-30TE-17
D1729 VHDRB551V30-1Y AC J Diode RB551V-30TE-17
D1730 VHDBAS316//-1Y AB J Diode BAS316,115
D1733 VHDRB551V30-1Y AC J Diode RB551V-30TE-17
D1734 VHDRB551V30-1Y AC J Diode RB551V-30TE-17
D1761 VHDBAS316//-1Y AB J Diode BAS316,115
D2531 VHEPZM12NB2-1Y AC J Zener Diode PZM12NB2
D2532 VHEPZM12NB2-1Y AC J Zener Diode PZM12NB2
D2551 VHEPZM12NB2-1Y AC J Zener Diode PZM12NB2
