Sharp XR-32X-L Service Manual

XR-32S-L/XR-32X-L/PG-F212X-L
10
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
Q2573 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q2574 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q2575 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q2801 VSRDTC114EE-1Y AA J Transistor PDTC114EE,115 (XR-32X-L/PG-F212X-L)
Q2802 VSRDTC114EE-1Y AA J Transistor PDTC114EE,115 (XR-32X-L/PG-F212X-L)
Q2803 VSRDTC114EE-1Y AA J Transistor PDTC114EE,115 (XR-32X-L/PG-F212X-L)
Q2804 VSUM6K1NTN+-1Y AC J Transistor UM6K1NTN (XR-32X-L/PG-F212X-L)
Q3001 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R (PG-F212X-L)
Q3102 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q3105 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R (PG-F212X-L)
Q3106 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R (PG-F212X-L)
Q3107 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R (PG-F212X-L)
Q3108 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q3109 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q3110 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q3301 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q3307 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q3308 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q3311 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q3321 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q3325 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R (PG-F212X-L)
Q3326 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q3501 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q3502 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q3511 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R (XR-32X-L/PG-F212X-L)
Q3512 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R (XR-32X-L/PG-F212X-L)
Q3521 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R (XR-32X-L/PG-F212X-L)
Q3524 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R (XR-32X-L/PG-F212X-L)
Q3534 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q3535 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q3536 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q3601 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q3801 VSMCH3405++-1Y AD J Transistor MCH3405-TLE
Q3802 VSTPC8021H+-1Y AG J
Transistor TPC8021-H(TE12L,Q)
Q3805 VSRTQ035P02-1Y AD J Transistor RTQ035P02TR
Q3806 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
R1701 VRS-CY1JF101JY AA J Resistor 100 1/16W Metal Oxide
R1702 VRS-CY1JF472JY AA J Resistor 4.7k 1/16W Metal Oxide
R1703 VRS-CH1JF100JY AA J Resistor 10 1/16W Metal Oxide
R1704 VRS-CY1JF100JY AA J Resistor 10 1/16W Metal Oxide
R1705 VRS-CY1JF100JY AA J Resistor 10 1/16W Metal Oxide
R1706 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R1707 VRS-CY1JF223JY AA J Resistor 22k 1/16W Metal Oxide
R1708 VRS-CY1JF152JY AA J Resistor 1.5k 1/16W Metal Oxide
R1710 VRS-CY1JF472JY AA J Resistor 4.7k 1/16W Metal Oxide
R1714 VRS-TW2HF1R0JY AA J Resistor 1 1/2W Metal Oxide
R1715 VRS-CY1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R1716 VRS-TV1JD000JY AA J Resistor 0 1/16W Metal Oxide
R1719 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R1721 VRS-CY1JF332JY AA J Resistor 3.3k 1/16W Metal Oxide
R1722 VRS-CY1JF622FY AA J Resistor 6.2k 1/16W Metal Oxide
R1723 VRS-CY1JF122JY AA J Resistor 1.2k 1/16W Metal Oxide
R1724 VRS-CY1JF392FY AA J Resistor 3.9k 1/16W Metal Oxide
R1725 VRS-CY1JF563JY AA J Resistor 56k 1/16W Metal Oxide
R1726 VRS-CH1JF562JY AB J Resistor 5.6k 1/16W Metal Oxide
R1727 VRS-CY1JF000JY AA J Resistor 0 1/16W Metal Oxide
R1728 VRS-CY1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R1731 VRS-CY1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R1738 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R1739 VRS-CY1JF104JY AA J Resistor 100k 1/16W Metal Oxide
R1740 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R1743 VRS-CY1JF680JY AA J Resistor 68 1/16W Metal Oxide
R1748 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R1749 VRS-TW2HF2R7JY AA J Resistor 2.7 1/2W Metal Oxide
R1752 VRS-CY1JF123FY AA J Resistor 12k 1/16W Metal Oxide
R1753 VRS-CY1JF104JY AA J Resistor 100k 1/16W Metal Oxide
R1756 VRS-CY1JF103FY AA J Resistor 10k 1/16W Metal Oxide
R1757
VRS-TW2HF2R7JY AA J Resistor 2.7 1/2W Metal Oxide
R1758 VRS-CY1JF680JY AA J Resistor 68 1/16W Metal Oxide
R1762 VRS-CY1JF682FY AA J Resistor 6.8k 1/16W Metal Oxide
R1763 VRS-CY1JF102FY AA J Resistor 1k 1/16W Metal Oxide
R1764 VRS-TW2ED000JY AB J Resistor 0 1/4W Metal Oxide
R1765 VRS-TW2ED000JY AB J Resistor 0 1/4W Metal Oxide
R1766 VRS-CY1JF222FY AA J Resistor 2.2k 1/16W Metal Oxide
R1768 VRS-CY1JF100JY AA J Resistor 10 1/16W Metal Oxide
R1769 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R1771 VRS-CY1JF473FY AA J Resistor 47k 1/16W Metal Oxide
R1772 VRS-CY1JF273FY AA J Resistor 27k 1/16W Metal Oxide
R1773 VRS-CY1JF152FY AA J Resistor 1.5k 1/16W Metal Oxide
R1782 VRS-CY1JF392FY AA J Resistor 3.9k 1/16W Metal Oxide
R1783 VRS-CY1JF102FY AA J Resistor 1k 1/16W Metal Oxide
R1789 VRS-CY1JF101JY AA J Resistor 100 1/16W Metal Oxide
R1793 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R1795 VRS-TW2HF2R2JY AA J Resistor 2.2 1/2W Metal Oxide
R1798 VRS-TW2HF1R0JY AA J Resistor 1 1/2W Metal Oxide
[2] DUNTKE390FMG4/5/6 (MAIN Unit)
