Shelly Plug S User Manual

Device Inclusion
To add a new Shelly device, install it to the power grid following the Installation
Instructions included with the Device.
Step 1
After the installation of Shelly following the Installation Instructions and the power is
turned on, Shelly will create its own WiFi Access Point (AP).
⚠WARNING! If the LED does not flash red/blue, press and hold the Button for at least
10 seconds. The LED should then flash red/blue. If not, please repeat or contact our
customer support at: support@shelly.cloud
Step 2
Choose “Add Device”. In order to add more Devices later, use the app menu at the top
right corner of the main screen and click “Add Device”. Type the name (SSID) and
password for the WiFi network, to which you want to add the Device.

Shelly Plug S Specifications

General

Frequency range	2.4 - 2.5 GHz
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Wireless technology	Wi-Fi
Connectivity technology	Wireless
Best uses	Home
Certification	RE Directive 2014/53/EU LVD 2014/35/EU EMC 2004/108/WE RoHS2 2011/65/UE
Product color	White
Placement supported	Indoor
Maximum indoor range	30 m
Maximum outdoor range	50 m
Maximum current	12 A
AC input voltage	110 - 230 V
AC input frequency	50 - 60 Hz
Maximum input power	2500 W
Operating temperature (T-T)	-20 - 40 °C
Mobile operating systems supported	Android 4.2, Android 4.2.1, Android 4.2.2, Android 4.3, Android 4.4, Android 5.0, Android 5.1, Android 6.0, Android 7.0, Android 7.1, Android 7.1.2, Android 8.0, Android 9.0, iOS 10.0, iOS 11.0, iOS 11.4, iOS 12, iOS 13, iOS 8.0, iOS 8.1, iOS 8.2, iOS 8.3, iOS 8.4, iOS 9.0, iOS 9.1, iOS 9.2, iOS 9.3

Weight and Dimensions

Depth	70 mm
Width	44 mm
