20
Step 10: Ensure all hardware is tightened properly following recommended torque values.
Recommended Torque Values
Hardware Location
Hardware
Torque Required (Nm)
Handlebar Area
Handlebar Stem Clamp Bolts
15
Handlebar Area
Handlebar Stem Faceplate Bolts
10
Handlebar Area
Brake Lever Clamp Bolt
6
Handlebar Area
Shifter Clamp Screw
6
Brakes
Caliper Adapter to Frame
6-8
Brakes
Caliper to Adapter
6-8
Brakes
Brake Cable to Caliper Clamp
6-8
Brakes
Disc Brake Rotor to Hub
7
Seatpost Area
Seat Angle Adjustment Bolt
20
Rear Dropout Area
Rear Axle Nuts
40
Rear Dropout Area
Rear Torque Arm Bolt
5
Rear Dropout Area
Derailleur Bash Guard Mounting Bolts
5
Rear Dropout Area
Derailleur Hanger Mounting Bolt
6
Rear Dropout Area
Derailleur Mounting Bolt
10
Rear Dropout Area
Derailleur Cable Pinch Bolt
6-8
Rear Dropout Area
Kickstand Mounting Bolts
8
Bottom Bracket and Crank Area
Bottom Bracket and Lockring
60
Bottom Bracket and Crank Area
Crank Arm Bolt into Bottom Bracket Spindle
35
Bottom Bracket and Crank Area
Pedal into Crank Arm
35
Bottom Bracket and Crank Area
Chainring Bolts
10
Bottom Bracket and Crank Area
Controller Mounting Bolts
6
Fenders
All Fender Mounting Bolts and Hardware
6
