Chapter 6 Inverter of function parameter
Chapter 6
79
No. Code
Describing LED/OLED
Keyboard display
Setting range
Factory setting
Change
51
P03.01 Rated power of motor 0.4～900.0Kw
Type setting
□
52
P03.02
Rated frequency of
motor
0.01Hz～P01.07(maximum
frequency)
50.00Hz
□
53
P03.03
Rated rotate speed of
motor
0～36000rPm
Type setting
□
54
P03.04
Rated voltage of
motor
0～460V
Type setting
□
55
P03.05
Rated current of
motor
0.1～2000.0A
Type setting
□
Notice: please make the setting based on the nameplate parameter of the motor. Excellent control
performance of vector control requires accurate motor parameter.
AC frequency vector inverter provides function for self-study of parameter. Accurate self-study of
parameter comes from correct input for the nameplate parameter of the motor.
Please guarantee the match between AC frequency vector inverter and motor in order to guarantee
the control performance; if their difference is very obvious, the control performance of AC frequency
vector inverter will obviously reduce.
Notice: resetting rated power (P03.01) of the motor will initialize motor parameter of P03.06~
P03.10.
56
P03.06
Stator resistor of
motor
0.001～65.535Ω
Type setting
◇
57
P03.07
Rotor resistance of
motor
0.001～65.535Ω
Type setting
◇
58
P03.08
Stator and rotor
inductance of motor
0.1～6553.5mH
Type setting
◇
59
P03.09
Mutual inductance for
stator and rotor of
motor
0.1～6553.5mH
Type setting
◇
60
P03.10
No-load current of the
motor
0.01～655.35A
Type setting
◇
After normal self-study of motor parameter, setting value of P03.06 ～ P03.10 will automatically
update. These parameters are basic parameters for vector control with high performance; and they have
direct effect on the performance of the control.
61
P03.11
self-study of motor
parameter
0: No operation
1: Comprehensive self-study of
parameter
2: Static self-study of parameter
0
□
