Sherwin-Williams 3040 - Pump Parts and Repair Kits (3040;3235); Pump Component Part Numbers; Pump Repair Kit Contents

824120 15
Parts: Pump for 3040 and 3235 Pressure Washers
Pump Model 803737, Series A
Ref.
No. Part No. Description Qty.
Ref.
No. Part No. Description Qty.
1 801467 MANIFOLD 1
2 801468 SCREW, cap, hex hd 8
3 801469 WASHER, lock 8
4 KIT 1 O-RING
5 KIT 1 SEAT, valve
6 KIT 1 PLATE, valve
7 KIT 1 SPRING
8 KIT 1 GUIDE, valve
9 KIT 4 O-RING
10 KIT 4 CAP
11 KIT 1 VALVE ASSEMBLY (includes 4 to 8)
12 803283 SCREW, cap, socket hd 8
13 803284 COVER, crankcase 1
14 802500 O-RING, crankcase cover 2
15 803285 BEARING, tapered roller 2
16 KIT 2 SEAL, oil
17 803286 BUSHING, piston 1
18 802895 CRANKCASE 1
19 801475 DIPSTICK 1
20 803144 GASKET, cover 1
21 803332 CRANKSHAFT 1
22 803288 RING, retaining 6
23 802794 KEY 1
24 803289 PIN, wrist 3
25 803290 GUIDE, piston 3
26 803291 ROD, connecting 1
27 803292 SCREW, cap, socket hd 5
28 803293 COVER, crankcase 1
29 802345 GAUGE, sight 1
30 802793 PLUG, oil drain 1
31 KIT 6 O-RING
32 803294 SCREW, cap, socket hd 6
33 801652 WASHER, lock 6
34 801660 WASHER, flinger 3
and KIT 6
35 801490 PLUNGER, ceramic 3
36 KIT 6 RING, backup
37 KIT 6 WASHER
38 KIT 6 SCREW, piston
39 803295 COVER, crankcase 1
40 803296 SHIM 2
41 KIT 3 SEAL, oil
42 KIT 28 O-RING
43 KIT 28 RETAINER, packing
44 KIT 8, 28 PACKING
45 KIT 28 RING, head
46 KIT 28 RETAINER, packing
47 KIT 28 RING, long life
48 801526 BRACKET, pump 2
49 802305 SCREW, cap, socket hd 2
50 802304 WASHER, lock 2
51 801482 PLUG, hex 1
52 801483 WASHER, flat 1
53 801484 PLUG, hex 1
54 801485 WASHER, flat 1
56 803083 LABEL, prevent freezing 1
Pump Repair Kits for 3040 and 3235 Pressure Washers
Kit
No.
Repair Kit
Part No.
Ref.
No. Description Qty
1
801472
Valve
Assembly
11
4
5
6
7
8
VALVE ASSEMBLY
(includes 4 to 8)
O-RING
SEAT, valve
PLATE, valve
SPRING
GUIDE, valve
6
6
6
6
6
6
2
801473
Oil Seal
16 SEAL, oil 3
3
802511
Crankshaft
Seal
41 SEAL, oil 2
4
802306
Valve
Cap
9
10
O-RING
CAP
6
6
Kit
No.
Repair Kit
Part No.
Ref.
No. Description Qty
6
801474
Plunger
Repair
31
34
36
37
38
O-RING
WASHER, flinger
RING, backup
WASHER
SCREW, piston
3
3
3
3
3
8
801486
Packing
44 PACKING 6
28
801487
Packing
and
Retainer
42
43
44
45
46
47
O-RING
RETAINER, packing
PACKING
RING, head
RETAINER, packing
RING, long life
1
1
2
1
1
1
