Shield Omega-X - Panel Controls and Indicators

Overview 2
Panel Controls and Indicators
The Omega - X front-panel contains the following controls and indicators:
• LCD display
• Upper-control-pad
• Lower-control-pad
• Left-panel-indicators
• Right-panel-indicators
The figure below illustrates the Omega - X front-panel:
Figure 2-2
Controls and Indicators
Key Description
1 LCD display
2 Left-panel-indicators
3 Upper-control-pad
4 Lower-control-pad
5 Right-panel-indicators
2 4513
