Shield SD1010 - SHIELD Vertical Sidewall Sprinkler Installation & Safety; Warnings; Wrench Description; Installation Guide

18
www.shieldglobal.com
WARNINGS
The SHIELD must be installed and maintained in
compliancewiththisdocument.Depressurizeanddrainthe
piping system before attempting to install, remove, or adjust
anySprinklers.Failuretodosomayimpairtheperformance
ofthesesprinklers.Theownerisresponsibleformaintaining
the re protection system and devices in operation.
WRENCH DESCRIPTION
The Sprinkler Wrench is a tool specically designed for
installingSHIELDSprinklers.Thesespecialwrenchesmust
be used to provide the proper leverage when tightening the
sprinklerandtominimizeslippageduringinstallation.Any
otherwrenchmaydamagethesprinkler.
INSTALLATION
All SHIELD Sprinklers must be installed according to
NFPA 13 Standards.Deviations from these requirements
and standards or any alteration to the sprinkler itself will
void any warranty made by manufacturer. In addition,
installation must also meet local government provisions,
codesandstandardsasapplicable.
The system piping must be properly sized to insure the
minimumrequiredowrateatthesprinkler.Checkforthe
proper model, style, orice size and temperature rating
prior to installation.Installsprinklersafterthepipingisin
place to avoid mechanical damage, replace any damaged
units.Wetpipesystemsmustbeprotectedfromfreezing.
Upon completion of the installation, the system must be
testedperrecognizedstandards.Intheeventofathread
task, remove the unit, apply new pipe joint compound or
tape,andreinstall.
ADDITIONAL
RecessedSprinkler-Toinstalltheescutcheonplate,align
with it and push or thread over the sprinkler body into the
upper support piece, until the outer edge of the escutcheon
meetsthemountingsurface.
INSTALLATION SEQUENCE
Step1.Theunitmustbeinstalledinthehorizontalsidewall
positionfortheHorizontalSidewallSprinklers.
Step2.Useonlyanon-hardeningpipejointcompoundor
tapeseal.Applyonlytothemalethreads.
Step3.Handtightenthesprinklerintotting.
Step 4. For Horizontal Sidewall Sprinklers, use a
standard wrench. Tighten the unit into the tting. A
lead-tightjointrequiresonly7to14ft.-lbs(9.5to19.0Nm)of
torque.Atangentialforceof14to28ft.-lbs(62.3to124.5N)
deliveredthrougha6”(150mm)handlewilldeliveradequate
torque. Once torque level reach over 21ft.-lbs(28.6Nm)
it may distort the orice seal, resulting in leakage. For
exposedpipingsystems,thesprinklershouldbeoriented
sotheframearmsareparallelwiththebranchlinepipe.
CAUTION
Do not over-tighten or under-tighten the sprinkler to
compensate for inaccurateescutcheonplate adjustment.
Protectionclipsareusedtoprotectitsbulb.Pleasehave
cliponatalltimesduringtransportation.
MAINTENANCE
Sprinklers must never be altered after manufacture. Any
alteration such as painting and coating will directly harm
thesprinklerandcausemalfunctions.Sprinklerincontact
with corrosive products should be replaced if they cannot
becleanedcompletely.
Visual inspections are recommended after installation.
After installation, a close-up inspection annually will
sufce.
Inspection and maintenance of re protection system is
the responsibility of the owner. It is recommended that
automatic sprinkler system be inspected and tested
accordingtolocaland/ornationalregulations.
Sprinkler Wrench
