www.shieldglobal.com

PART LIST

SD1021SD1020

FRAMEANDDEFLECTORFINISH

Pendent - Brass, Chrome, White

Upright - Brass only

1.Frame2.Deector3.Cap4.CapSeat5.LoadScrew6.Seal7.Bulb

DISCHARGE CURVE
