WARNINGS
The SHIELD sprinklers must be installed and maintained
incompliancewiththisdocument.Depressurizeanddrain
the piping system before attempting to install, remove,
oradjustanySprinklers.Failure todo somayimpair the
performanceofthesesprinklers.Theownerisresponsible
formaintaining the re protection systemand devicesin
operation.
WRENCH DESCRIPTION
The Sprinkler Wrench is a tool specically designed for
installingSHIELDSprinklers.Thesespecialwrenchesmust
be used to provide the proper leverage when tightening the
sprinklerandtominimizeslippageduringinstallation.Any
otherwrenchmaydamagethesprinkler.
INSTALLATION
All SHIELD Sprinklers must be installed according to
NFPA 13 Standards. Deviations fromthese requirements
and standards or any alteration to the sprinkler itself will
void any warranty made by manufacturer. In addition,
installation must also meet local government provisions,
codesandstandardsasapplicable.
The system piping must be properly sized to insure the
minimumrequiredowrateatthesprinkler.Checkforthe
proper model, style, orice size and temperature rating
prior to installation.Installsprinklersafterthepipingisin
place to avoid mechanical damage, replace any damaged
units.Wetpipesystemsmustbeprotectedfromfreezing.
Upon completion of the installation, the system must be
testedperrecognizedstandards.Intheeventofathread
task, remove the unit, apply new pipe joint compound or
tape,andreinstall.
ADDITIONAL
Recessed Sprinkler - To install the escutcheon plate,
align with it and push or thread over the sprinkler body
into the upper support piece, until the outer edge of the
escutcheonmeetsthemountingsurface.
INSTALLATION SEQUENCE
Step1.Theunitmustbeinstalledinthehorizontalsidewall
positionfortheHorizontalSidewallSprinklers.
Step2.Useonlyanon-hardeningpipejointcompoundor
tapeseal.Applyonlytothemalethreads.
Step3.Handtightenthesprinklerintotting.
Step 4. For Horizontal Sidewall Sprinklers, use a
standardwrench.Tightentheunit intothetting.Alead-
tight joint requires only 7 to 14ft.-lbs(9.5 to19.0Nm) of
torque.Atangentialforceof14to28ft.-lbs(62.3to124.5N)
deliveredthrougha6”(150mm)handlewilldeliveradequate
torque. Once torque level reach over 21ft.-lbs(28.6Nm)
it may distort the orice seal, resulting in leakage. For
exposedpipingsystems,thesprinklershouldbeoriented
sotheframearmsareparallelwiththebranchlinepipe.
CAUTION
Do not over-tighten or under-tighten the sprinkler to
compensateforinaccurateescutcheonplateadjustment.
Protectionclipsareusedtoprotectitsbulb.Pleasehave
cliponatalltimesduringtransportation.
MAINTENANCE
Sprinklers must never be altered after manufacture. Any
alteration such as painting and coating will directly harm
thesprinklerandcausemalfunctions.Sprinklerincontact
with corrosive products should be replaced if they cannot
becleanedcompletely.
Visual inspections are recommended after installation.
After installation, a close-up inspection annually will
sufce.
Inspection and maintenance of re protection system is
the responsibility of the owner. It is recommended that
automatic sprinkler system be inspected and tested
accordingtolocaland/ornationalregulations.
Sprinkler Wrench
