31
9. Specifications
9. Specifications
Print method Impact dot
Inking Ink ribbon
Print format 24 digits / line (5 × 7 dot matrix)
Printing speed 2.7 lines / sec. (approx.)
Character size 1.7mm (W) × 2.6mm (H)
Printer paper Normal paper 57.5mm width
Printing
Printer mechanism durability 1.5 million lines
Operation temperature range 5-40°C
AC AC adapter (Output : DC 9 - 12V 2A)
Power
source
Battery operation Dry batteries (Alkaline only) R6 (size AA) × 6pcs (not provided)
Battery life: 10 hours approx.
(when prints 1 line / 5 seconds continuously at 20°C)
Interface Serial I/O, TTL level
Physical dimensions 154 (W) × 78.5 (H) × 215 (D) mm approx.
Weight 630g approx.
Functions Statistical calculations, Date and time print-out (with balance’s
built-in clock), ID number, Sample number print-out,
xK data output, Comparator print-out, Auto print, Commands to
set on balance’s application functions (Formulation, Add-on,
Animal weighing, Percentage display)
