3.
4.
5.
6.
Please note: Specifications are subject to change for improvement without notice.
(English)
One Holland Irvine CA 92618 U.S.A. Phone 949-951-5003
Industrieweg 24 NL-8071 CT Nunspeet‚ Holland Phone 31-3412-72222
3-77 Oimatsucho‚ Sakai‚ Osaka‚ Japan Phone 0722-23-3243
3
3
4
4
3
4
=
A
B
+ =
3 -- 4 mm
A
B
1
1
1
2
2
+ =
3 -- 4 mm
A
B
=
A
B
2
Set the quick lever to the closed position; then adjust the
shoe clearance (as shown in the illustration below) and
secure the cable.
Cable connection
Quick lever
Open
Closed
Centering of the brake shoe
Check
Depress about
10 times
Cable adjustment bolt
Depress the brake lever about 10 times as far as the grip
and check that everything
is operating correctly
and that the shoe
clearance is correct
before using the
brakes.
Turn the cable adjustment bolt to readjust the shoe
clearance.
Readjustment of the shoe clearance
Make a minor adjustment by using the centering
adjustment bolt.
Centering adjustment bolt
Cable bolt tightening torque:
6 – 8 Nm {52 – 69 in. lbs.}
Apr. 1999 by Shimano Inc. PIT. SZK. Printed in Malaysia
