Preface
This instruction manual is intended for those who will be involved in wiring, installation,
operation and routine maintenance of the MAC3.
This manual describes the care, installation, wiring, function, and proper procedures
regarding the operation of MAC３.
Keep this manual on hand while using this device. Please follow the provided guidance.
1.
Matters regarding safety
For matters regarding safety, potential damage to equipment and/or facilities and additional
instructions are indicated as follows:
This mark indicates hazardous conditions that could cause injury or death of personnel.
Exercise extreme caution as indicated.
「
「「
「
WARNING」
」」
」
This mark indicates hazardous conditions that could cause damage to equipment and/or
facilities. Exercise extreme caution as indicated.
「
「「
「
CAUTION」
」」
」
This mark indicates additional instructions and/or notes.
「NOTE」
「
「「
「
WARNING」
」」
」
MAC3 is designed for controlling temperature, humidity, and other physical subjects in general
industrial facilities. It must not be used in any way that may adversely affect safety, health, or
working conditions.
「
「「
「
CAUTION」
」」
」
To avoid damage to the connected equipment, facilities or the product itself due to a fault of
this instrument, safety countermeasures must be taken before usage, such as proper installation
of the fuse and the overheating protection device. No warranty, expressed or implied, is valid in
the case of usage without having implemented proper safety countermeasures.
「
「「
「
ＣＡＵＴＩＯＮ」
ＣＡＵＴＩＯＮ」ＣＡＵＴＩＯＮ」
ＣＡＵＴＩＯＮ」
The mark on the plate affixed to the instrument:
On the terminal nameplate affixed to the case of your instrument, the mark is printed.
This is to warn you of the risk of electrical shock which may result if the charger is touched
while it is energized.
The external power circuit connected to the power terminal of this instrument must have a
means of turning off the power, such as a switch or breaker. Install the switch or breaker
adjacent to the instrument in a position which allows it to be operated with ease, and with
an indication that it is a means of turning off the power. Use a switch or breaker, which
meets the requirements of IEC127.
Fuse:
Since the instrument does not have a built-in fuse, do not forget to install a fuse in the
power circuit to be connected to the power terminal. The fuse should be positioned
between the switch or breaker and the instrument and should be attached to the L side of
the power terminal.
Fuse Rating: 250V AC 0.5A/medium lagged or lagged type.
Use a fuse which meets the requirements of IEC127
Load voltage/current to be connected to the output terminal and the alarm terminal should
be within the rated range. Otherwise, the temperature will rise and shorten the life of the
product and/or result in problems with the product.
Voltage/current that differs from input specification should not be connected to the input
terminal. It may shorten the life of the product and/or result in problems with the product.
Input, output of voltage pulse, and output of electric current are not insulated. Therefore, do
not ground an adjusted power terminal when a ground sensor is employed.
A signal wire's common mode voltage to ground (signal wires other than contact output
including power supply and event) should be less than 30V rms, 42.4V peak, and 60 VDC .
「
「「
「
CAUTION」
」」
」
All the wires for the interior distribution, except for communication and contact output (including
power supply and event), should be less than 30m in length. When the wire's length is 30m or more,
or in the case of outdoor wiring, the suitable measure against a lightning surge is required.
EMC standard (IEC61326) classifies MAC3 into Class A apparatus. Electromagnetic interference
may occur when MAC3 is used at a business district or in the home. Please use after taking
sufficient measures.
2. Introduction
2-1. Check before use
Before using MAC3, please check the model code, the exterior appearance and accessories. Also,
make sure that there are no errors, impairs and shortages.
Confirmation of model code: Check that the product you ordered is being delivered properly.
Check the model code of the main body case against the following code table.
Example of model code
ＭＡＣ３Ａ－
ＭＡＣ３Ａ－ＭＡＣ３Ａ－
ＭＡＣ３Ａ－ Ｍ
ＭＭ
Ｍ Ｃ
ＣＣ
Ｃ
Item
1. Series MAC3A-:96×96mm size digital controller
MAC3B-:48×96mm size digital controller
2. Input M:multi, V:voltage, I:current
3.Control Output 1 C:contact, S:voltage pulse, I:current(4～20mA),V:Voltage(0～10V)
4. Power Supply F-:90 - 264V AC, L-:21.6 - 26.4V DC/AC
5. Event Output N:none, E:Event Output１･2 (two points)
6.Control Output 2･Event Output･Optional Selection of DI
N-:none, C-:contact, S-:voltage pulse, I-:current (4～20mA), V:Voltage(0～10V)
E-: Event Output 3(one point), D-: external control input (DI4) one point
7. DI N:none, D: external control input (DI 1,2,3) three points8
8. CT Input N: none, H: CT Input two points
9. Analog Output N: none, I: current (4～20mA)
10. Communication N: none, R: RS485
11. Program Function N: none, P: equipped
Example of model code
ＭＡＣ３Ｄ－
ＭＡＣ３Ｄ－ＭＡＣ３Ｄ－
ＭＡＣ３Ｄ－ Ｍ
ＭＭ
Ｍ Ｃ
ＣＣ
Ｃ
1 2 3 4 5 6 7 8 9
Items
1. Series MAC３Ｃ:72×72mm size digital controller
MAC3D-: 48×48mm size digital controller
2. Input M:multi, V: voltage, I:current
3.Control Output 1 C:contact, S:voltage pulse, I:current(4～20mA) V:Voltage(0～10V),
4. Power Supply F-:90 - 264V AC, L-:21.6 - 26.4V DC/AC
5. Event Output N:none, E:Event Output１･2 (two points)
6.Control Output 2･Event Output･Optional Selection of DI
N-:none, C-:contact, S-:voltage pulse, I-:current (4～20mA) V:Voltage(0～10V)
E-: Event Output 3(one point), D-: external control input (DI4) one point
7. DI･CT Input N: none, D: external control input (DI1,2,3) three points, H:CT Input two points
8. Analog Output･Communication N: none, T: current (4～20mA), R: RS485
9. Program Function N: none, P: equipped
Check of accessories
Instruction manual: 1 set
｢NOTE｣ : Please contact our agencies or business offices if you have any problem.
We welcome any kind of inquiry such as defect of the product, shortage of accessory
and so on.
2-2. Caution for use
(1) Do not operate the front panel keys with hard or sharp objects.
Do not fail to touch keys lightly with a fingertip.
(2) Wipe gently with a dry rag and avoid using solvents such as thinner.
3. Installation and wiring
3-1. Installation site (environmental conditions)
「
CAUTION」
Do not use this product under the following conditions.
Otherwise, failure, damage and fire may occur.
(1) Where flammable gas, corrosive gas, oil mist or dust generate or grow rife.
(2) Where the temperature is below -10℃ or above 55℃
(3) Where the humidity is over 90%RH or where condensation occurs.
(4) Where high vibration or impact occurs
(5) Where inductive interference may easily affect the operation.
Or, in the region of strong electric circuit area.
(6) Where waterdrops or direct sunlight exists.
(7) Where the altitude is above 2,000m.
「NOTE」: The environmental conditions comply with the IEC664.
Installation category isⅡ and the pollution degree is 2.
