Shining KF-70GW - 24000 Btu

11
unit（mm）
Air inlet
Air lter
Air outlet
Horizontal grill
Vertical grill
（by hand）
Sleep
Timer
Running
(blinking when fault)
1090
330
220
55
40
80
55
Hole center ofφ65Hole center ofφ65
Indoor unit
Name of parts
Installation dimension
Front cover
Place for opening the cover
Power wire
Temporary switch
Signal receiver
Dimensions
24000Btu
