GB-IE Attach the smaller inner part of the 3 point hinges on the long edge of the door.
02
Door
(DR3)x01
Continuous hinge
(CH-1105)x01
Screw
(25mm)x14
Wooden Knob
(WKB)x01
Black ring handle
(B-RH)x01
Screw
(45mm)x01
Black screw
(25mmFH)x04
45
GB-IE Position the "black ring handle B-RH" on the outside over the door framework, mark the screw holes as
shown, drill the middle hole only for the "wooden knob WKB", attach the wooden knob on the inside of
the door first with the 45mm flat head screw and then attach the ring handle on the outside of the door
over the flat head screw.
6mm
6mm
12
To Next Page
