Shire Cubby - Window Hinge Fitting; Window Fixing

GB-IE Position the window insert in the aperture and screw the inner screw holes that are just visible first.
Open the window and insert the remaining screws.
14
06
05
Hinge
(STH)x02
Screw
(25mm)x04
Window insert
(WI4) x01
GB-IE Try the window in position in the panel to check that you have it the correct way around.
The hinges fit the top of the window.
Screw
(25mm)x10
