Shire Cubby - Gable Panels Attachment; Safety Vent Installation

GB-IE Place the Back Gable "GP3-b " panel level with the framework and fix to the panel below .
Repeat with the front gable.”GP3-F”
11
10
Screw
(60mm) x08
Back Gable
GB-IE Push the vents into the holes in the back gable panel.
Front Gable
(GP4-F) x01
Safety vent
(VNT) x01
6mm
17
