Air Conditioner Service Manmual
Connection
Pipe
Length (m) 15
Max Distance
Height (m) 5
Net Weight /Gross Weight (kg) 36.5/39.6
Gas Pipe (mm) Φ12(1/2'')
Outer Diameter
Liquid Pipe (mm) Φ6(1/4'')
Gas additional charge(g/m) 30
Length (m)
5
Refrigerant Charge (kg) 1050
Permissible Excessive Operating Pressure fo
r
theDischarge Side(MPa)
29
Dimension of Package (L/W/H)( mm) 863*590*361
Dimension (W/H/D) ( mm)
823x552x256
Sound Power Level dB (A) (H/M/L)
Sound Pressure Level dB (A) (H/M/L) 58
Permissible Excessive Operating Pressure fo
r
theSuction Side(MPa)
0.75
Fan Type Axial fan
Moisture Protection IP24
Isolation I
Climate Type T1
Defrosting Method Auto defrost
Fan Diameter (mm) φ409×132
Coil length (l) X height (H)Xcoil width (L) 768*510*19.05
Air Flow Volume of Outdoor Unit(m3/h) 2340
Fan Motor Capacitor (μF) 3
Fan Motor RLA(A) 0.47
Output of Fan Motor (W) 45
Fan Motor Speed (rpm) 850
Throttling Method Capillary
Rows-Fin Gap(mm) 1-1.5
Pipe Diameter (mm) Φ9.52
Condenser Hydrophilic aluminum fin-copper tube
Working Temp Range (ºC) 18-43
Starting Method Capacitor
IOL
Compressor Power Input(W) 1650
Compressor RLA(A) 7.7
Outdoorunit
Model of Outdoor Unit
SRH-I184BE
L.R.A. (A) 40
Compressor Type Rotary
Compressor Model ASH201SV-C8LU
Overload Protector
Compressor Manufacturer/trademark HIGHLY
Product Code /
11
