SRH-L094DC-W SRH-L094DC-S
Air Conditioner Service Manual
Connection
Pipe
Length (m)
Max Distance
Height (m)
Net Weight /Gross Weight (kg) 32/36
Gas Pipe (mm) Ф9.52(3/8)
Outer Diameter
Liquid Pipe (mm) Φ6(1/4'')
Gas additional charge(g/m) 20
Length (m)
5
Refrigerant Charge (kg) 1002
P
erm
i
ss
ibl
e
E
xcess
i
ve
O
pera
ti
ng
P
ressure
f
o
r
theDischarge Side(MPa)
4.5
Dimension of Package (L/W/H)( mm) 863x590x361
Dimension (W/H/D) (mm) 826x552x256
Sound Power Level dB (A) (H/M/L)
Sound Pressure Level dB (A) (H/M/L) 52
Permissible Excessive
O
perating Pressure
f
o
r
theSuction Side(MPa)
1.9
Fan Type Axial fan
Moisture Protection IP25
Isolation I
Climate Type T1
Defrosting Method Auto defrost
Fan Diameter (mm) φ408×132
Coil length (l) X height (H)Xcoil width (L) 756x510x25.4
Air Flow Volume of Outdoor Unit(m3/h) 2340
Fan Motor Capacitor (μF) 2.5
Fan Motor RLA(A) 0.45
Output of Fan Motor (W) 31
Fan Motor Speed (rpm) 860
Throttling Method Capillary
Rows-Fin Gap(mm) 2-1.5
Pipe Diameter (mm) Φ7
Condenser Hydrophilic aluminum fin-copper tube
Working Temp Range (ºC) 18-44
Starting Method Capacitor
Compressor Power Input(W) 705±5%
Compressor RLA(A) 4.75±5%
Outdoorunit
Model of Outdoor Unit
L.R.A. (A) N.A
Compressor Type Rotary
Compressor Model DA89X1C-20FZ3
Overload Protector INT01L-4639
Compressor Manufacturer/trademark GMCC
Product Code /
15
