Shivaki SSH-I074BE - Page 17

SRH-L124DC-W SRH-L124DC-S
Length (m)
Max Distance
Height (m)
Gas Pipe (mm) Φ12(1/2'')
Outer Diameter
Liquid Pipe (mm) Φ6(1/4'')
Gas additional charge(g/m) 20
Connection
Pipe
Length (m)
5
Sound Pressure Level dB (A) (H/M/L) 55
Refrigerant Charge (kg) 1000
Net Weight /Gross Weight (kg) 32/36
Dimension of Package (L/W/H)( mm) 863x590x361
Dimension (W/H/D) ( mm) 760x552x256
Sound Power Level dB (A) (H/M/L)
Defrosting Method Auto defrost
Permissible Excessive Operating Pressure fo
r
theSuction Side(MPa)
1.9
P
erm
i
ss
ibl
e
E
xcess
i
ve
O
pera
ti
ng
P
ressure
f
o
r
theDischarge Side(MPa)
4.5
Moisture Protection IP26
Isolation I
Climate Type T3
Output of Fan Motor (W) 30
Fan Diameter (mm) φ408×132
Fan Type Axial fan
Air Flow Volume of Outdoor Unit(m3/h) 2340
Fan Motor Capacitor (μF) 2.5
Fan Motor RLA(A) 0.45
Working Temp Range (ºC) 18-45
Fan Motor Speed (rpm) 900 /770/670
Coil length (l) X height (H)Xcoil width (L) 756x510x25.4
Rows-Fin Gap(mm) 2-1.5
Pipe Diameter (mm) Φ7
Condenser Hydrophilic aluminum fin-copper tube
L.R.A. (A) N.A
Starting Method Capacitor
Throttling Method Capillary
Overload Protector IOL
Compressor Power Input(W) 865±5%
Compressor RLA(A) 4.6±5%
Outdoorunit
Model of Outdoor Unit
Compressor Type Rotary
Compressor Model DA108M1C-81EZ8
Compressor Manufacturer/trademark GMCC
Product Code /
