Product Dimensions
OB207t-1qxp 25/9/97 8:51 PM Page 12
Indoor Unit
A
B
20 mm
400 mm
57 mm
C
H
G
F
I
K
J
D
E
Unit: mm
Capacity A B C D E F G H I J K
9K&12K 800 280 185 760 552 256 290 328 48 507.8 63
Air Conditioner Service Manual
24
