No. Part No. Part Name Q’ty Remark
1 1080030008 Installation Plate 1
2 1210320107 Base 1
3 1070020026AA Cross Fan 1
4 1070100010 Bearing Mount 1
5 1110050067 Evaporator 1
6 1070320011 Water Drainage Assembly 1
7 1070320440 Vertical Vane Assembly 2
8 1070320445 Face Frame 1
9 1070320112 Screw Cover 2
10 1090251109 Display PCB 1
11 1070250425 Display PCB Box 1
12 1070320109 Air Filter 2
13 210701429 Front Panel 1
14 1070321073 Display PCB Cover 1
15 1170120045 Power Supply Cord 1
16 1070320439 Vane 1
17 1070110011 Drainage Hose 1
18 1070320114 Cable Clamp 1
19 1090320619 Main PCB 1
20 1070320113 Electrical Box 1
21 1170020011 Vane Motor 1
22 1073030201 Sensor Holder 1
23 1170030047 Indoor Motor 1
24 1070320111 Indoor Motor Cover 1
25 1170240001 Transformer 1
26 1170230001 Indoor Sensor Assembly 1
27 1070320101 In And Out Pipe Fixer 1
28 1090050298AN Remote Controller 1
29 1070060003 Remote Controller Supporter 1
30 1190060828HG Indoor Carton 1
31 1191990104 Left Foaming 1
32 1191990105 Right Foaming 1
Air Conditioner Service Manual
Not shown in Explosion view
Indoor Unit- SSH-I124
