No. Part No. Part Name Q’ty Remark
1 1071990064 Grille 1
Optional
2 1081990014 Top Cover 1
3 1110061064 Condenser 1
4 1081990018 Outdoor Motor Supporter 1
5 1170040062 Outdoor Motor 1
6 1070030006AA Propeller Fan 1
7 1081990011 Left Grille Supporter 1
8 1080320147 Left airproof plate 1
9 1081990016 Front Plate 1
10 1071990044 Fan Guard 1
11 1100120015 Compressor And It Accessories 1
12 1120110016 4-way Valve 1
13 1120251540 4-way Valve Assembly 1
14 1091990046 Base 1
15 1081990012 Right Plate 1
16 1120120025 Two-way Valve 1
17 1081990013 Valve Supporter 1
18 1120130039 Three-way Valve 1
19
1073521301
Electrical Box Cover 1
20 1070040001
Cable Clamp(φ6)
1
21 1070040002
Cable Clamp(φ7)
1
22 1170500131 Terminal 1
23 1170100031 Fan Motor Capacitor 1
24 1170100014 Compressor Capacitor 1
25 1080010002 Capacitor Strip 1
26 1081990010 Electrical Parts Box 1
27 1120200361 Capillary Assembly 1
28 1081990019 Partition plate 1
29 1174561802 Outdoor Sensor 1
30 1190070014 Base Carton 1
31 1190070008EC Cabinet Carton 1
32 1190070016 Base Foaming 1
33 1190070015 Cover Forming 1
Outdoor Unit- SRH-I074
BE
Air Conditioner Service Manual
Not shown in the Explosion view.
