Shivaki SSH-I074BE - Page 5

Air Conditioner Service Manual
Length (m)
Max Distance
Height (m)
Connection
Pipe
Length (m)
5
Dimension of Package (L/W/H)( mm) 745x550x353
Gas Pipe (mm) Ф9.52(3/8)
Outer Diameter
Liquid Pipe (mm) Φ6(1/4'')
Gas additional charge(g/m) 20
Refrigerant Charge (kg) 440
Net Weight /Gross Weight (kg) 23.3/25.3
Moisture Protection IP24
Dimension (W/H/D) ( mm)
655x500x232
Sound Power Level dB (A) (H/M/L)
Sound Pressure Level dB (A) (H/M/L) 50
Permissible Excessive Operating Pressure fo
r
theSuction Side(MPa)
0.65
Permissible Excessive Operating Pressure for the
Discharge Side(MPa)
2.8
Air Flow Volume of Outdoor Unit(m3/h) 1415
Isolation I
Climate Type T1
Defrosting Method Auto defrost
Fan Diameter (mm) φ324×119
Fan Type Axial fan
Rows-Fin Gap(mm) 1-1.8
Fan Motor Capacitor (μF) 2
Fan Motor RLA(A) 0.37
Output of Fan Motor (W) 25
Fan Motor Speed (rpm) 895
Coil length (l) X height (H)Xcoil width (L) 621*462*12.7
Overload Protector B145-140-141E
Pipe Diameter (mm) Φ7
Condenser Hydrophilic aluminum fin-copper tube
Working Temp Range (ºC) 18-43
Starting Method Capacitor
Throttling Method Capillary
QING'AN
Compressor Power Input(W) 780±5%
Compressor RLA(A) 3.8
L.R.A. (A) 19
Outdoorunit
Model of Outdoor Unit
SRH-I074BE
Compressor Type Rotary
Compressor Model YZG-E22RY2
Compressor Manufacturer/trademark
Product Code /
5
