No. Part No. Part Name Q’ty Remark
1 Installation Plate 1
2 Base 1
3 Cross Fan 1
4 Bearing Mount 1
5 Evaporator 1
6 Water Drainage Assembly 1
7 Vertical Vane Assembly 1
8 Face Frame 1
9 Screw Cover 3
10 Display PCB (digital) 1
11 Display PCB Box 1
Left Air Filter 1
Right Air Filter 1
13 Front Panel 1
14 Power Supply Cord 1
15 Vane 1
16 Drainage Hose 1
17 Cable Clamp 1
18 Terminal 1
19 Terminal fixing board 1
20 Main PCB(digital) 1
21 Electrical Box 1
22 Vane Motor 2
23 Sensor Holder 1
24 Indoor Motor 1
25 Indoor Motor Cover 1
26 Transformer 1
27 Indoor Sensor Assembly 1
28 In and out fixer 1
29 Remote Controller 1
30 Remote Controller Supporter 1
31 Indoor Carton 1
32 Left Foaming 1
33 Right Foaming 1
34 Middle Pasteboard Supporter 1
35 Base Foaming 1
Not shown in Explosion view
Indoor Unit- SSH-L094
DC-W,SSH-L094DC-S
Air Conditioner Service Manual
12
