OUTDOOR UNIT
Model:
SＳＨ－Ｌ０９4ＤＣ－Ｗ，SＳＨ－Ｌ０９4ＤＣ－Ｓ
No. Part No. Part Name Q’ty Remark
1 Grille 1
2 Top cover 1
3 Condenser 1
4 Outdoor motor supporter 1
5 Outdoor motor 1
6 Propeller fan 1
7 Left grille supporter 2
8 Front plate 2
9 Fan guard 1
10 Compressor and accessories 1
11 4-way valve 1
12 4-way valve assembly 1
13 Base 1
14 Right plate 1
15 Two-way valve 1
16 Valve supporter 1
17 Three-way valve 1
18 Electrical Box Cover 1
19 Cable clamp 1
20 Terminal 1
21 Electrical box 1
22 Inverter module 1
23 Power source board 1
24 Radiator 1
25 Inductor 1
26 Capillary assembly 1
27 Partition plate 1
28 Pipe Temp. sensor and outdoor
Temp. sensor
1
29 Discharge Temp. sensor 1
30 Base carton 1
31 Cabinet carton 1
32 Base foaming 1
33 Cover foaming 1
Air Conditioner Service Manual
Not shown in explosion view
