Connection
Pipe
Length (m)
Max Distance
Height (m)
Net Weight /Gross Weight (kg) 23.4/25.5
Gas Pipe (mm) Ф9.52(3/8)
Outer Diameter
Liquid Pipe (mm) Φ6(1/4'')
Gas additional charge(g/m) 20
Length (m)
5
Refrigerant Charge (kg) 470
Permissible Excessive
O
perating Pressure
f
o
r
theDischarge Side(MPa)
2.8
Dimension of Package (L/W/H)( mm) 745x550x353
Dimension (W/H/D) ( mm) 600x500x232
Sound Power Level dB (A) (H/M/L)
Sound Pressure Level dB (A) (H/M/L) 52
Permissible Excessive Operating Pressure for
theSuction Side(MPa)
0.65
Fan Type Axial fan
Moisture Protection IP24
Isolation I
Climate Type T1
Defrosting Method Auto defrost
Fan Diameter (mm) φ324×119
Coil length (l) X height (H)Xcoil width (L) 621*462*12.7
Air Flow Volume of Outdoor Unit(m3/h) 1415
Fan Motor Capacitor (μF) 2
Fan Motor RLA(A) 0.37
Output of Fan Motor (W) 25
Fan Motor Speed (rpm) 895
Throttling Method Capillary
Rows-Fin Gap(mm) 1-1.8
Pipe Diameter (mm) Φ7
Condenser Hydrophilic aluminum fin-copper tube
Working Temp Range (ºC) 18-43
Starting Method Capacitor
B175-145B-141C
Compressor Power Input(W) 930±5%
Compressor RLA(A) 4.3
Outdoorunit
Model of Outdoor Unit
SRH-I094BE
L.R.A. (A) 21
Compressor Type Rotary
Compressor Model 44A233AJ-FEKC
Overload Protector
Compressor Manufacturer/trademark RECHI
Product Code /
