Air Conditioner Service Manual
Length (m)
5
Gas additional charge(g/m) 20
Length (m) 15
Max Distance
Height (m) 5
Connection
Pipe
Gas Pipe (mm) Ф9.52(3/8)
Outer Diameter
Liquid Pipe (mm) Φ6(1/4'')
Sound Pressure Level dB (A) (H/M/L) 55
Refrigerant Charge (kg) 670
Net Weight /Gross Weight (kg) 29.7/32.8
Dimension of Package (L/W/H)( mm) 803*590*361
Dimension (W/H/D) ( mm)
755x552x256
Sound Power Level dB (A) (H/M/L)
Defrosting Method Auto defrost
Permissible Excessive
O
perating Pressure
f
o
r
theSuction Side(MPa)
0.7
Permissible Excessive
O
perating Pressure
f
o
r
theDischarge Side(MPa)
2.9
Moisture Protection IP24
Isolation I
Climate Type T1
Output of Fan Motor (W) 31
Fan Diameter (mm) φ401×119
Fan Type Axial fan
Air Flow Volume of Outdoor Unit(m3/h) 2040
Fan Motor Capacitor (μF) 2.5
Fan Motor RLA(A) 0.45
Working Temp Range (ºC) 18-43
Fan Motor Speed (rpm) 860
Coil length (l) X height (H)Xcoil width (L) 711*504*12.7
Rows-Fin Gap(mm) 1-1.5
Pipe Diameter (mm) Φ7
Condenser Hydrophilic aluminum fin-copper tube
30
Starting Method Capacitor
Throttling Method Capillary
Overload Protector B290-150B-241E
Compressor Type Rotary
Compressor Model 48A313PM-55KF
Compressor Manufacturer/trademark RECHI
Product Code /
Outdoorunit
Model of Outdoor Unit
SRH-I124BE
Compressor Power Input(W) 1245±5%
Compressor RLA(A) 5.8
L.R.A. (A)
9
