Model:SSH-P126DC
No. Part No. Part Name Q’ty Remark
1 1080030008 Installation plate 1
2 1080320806AC Base 1
3 1070020026AA indoor fan 1
4 1070100010 Bearing Mount 1
5 211205800 Evaporator 1
6 1070321572AC Water Drainage Assembly 1
7 1070321035 Vertical Vane Assembly 2
8 1070321678AE Face frame 1
9 1070321022AC Screw cover 2
10 1070320109 Air filter 2
11 1070252211 Display PCB box 1
12 1090321196 Display PCB 1
13 210706141 Panel 1
14 1170120045 Power supply cord 1
15 1070321034AE Vane 1
16 1070110011 Drainage hose 1
17 1070040004 Cable clamp 1
18 1170200042 Terminal 1
19 1070250109 Terminal fixing board 1
20 210900001AF main PCB 1
21 1070320113 Electrical box 1
22 1170020011 Vane motor 1
23 1073010501 Sensor holder 1
24 1170030067 Indoor motor 1
25 1070320111 Indoor motor cover 1
26 1170240001 Transformer 1
27 1170230001 indoor sensor assembly 1
28 1080320818AB In And Out Pipe Fixer 1
29 1090090001AL Remote controller 1
30 1070060003 Remote controller supporter 1
31 1190060828BKU Indoor cartoon 1
32 211310246 Left foaming 1
33 211310247 Right foaming 1
Air Conditioner Service Manual
Not shown in explosion view
