No. Part No. Part Name Q’ty Remark
1 1080030021 Installation Plate 1
2 1070350872AD Base 1
3 1070020024AA Cross Fan 1
4 1070100010 Bearing Mount 1
5 211205865 Evaporator 1
6 1070450385AR Water Drainage Assembly 1
7 1070350141 Vertical Vane Assembly 1
8 1070450900AG Face Frame 1
9 1070350135AF Screw Cover 3
10 1070450397 Air Filter 1
11 1070252211 Display PCB Box 1
12 1090321196 Display PCB 1
13 210706142 Front Panel 1
14 1170120045 Power Supply Cord 1
15 1070450387AP Vane 1
16 1070110011 Drainage Hose 1
17 1070040004 Cable Clamp 1
18 1170200042 Terminal 1
19 210800637 Terminal fixing board 1
18 210900001AM Main PCB 1
19 1070451080 Electrical Box 1
20 1170020041 Vane Motor 2
21 1073030201 Sensor Holder 1
22
1170030065
Indoor Motor 1
23 1070350152 Indoor Motor Cover 1
24 1170240001 Transformer 1
25 1170230001 Indoor Sensor Assembly 1
26 1070350245AD In And Out Pipe Fixer 1
27 1090090001AL Remote Controller 1
28 1070060003 Remote Controller Supporter 1
29 1190470001BJL Indoor Carton 1
30 1190060803 Left Foaming 1
31 1190060804 Right Foaming 1
32 211310757 Middle Pasteboard Supporter 1
Air Conditioner Service Manual
Indoor Unit- SSH-P186DC
Not shown in Explosion view
