D2260A Mini Mobile Base Instructions
3. Determine how you will get the machine on the
mobile base.
—Ifthemachinecanbelifted,followthe
instructions in Assembling Base, and Mounting
Machine onto Mobile Base on Page 11.
—Ifthemachinecannotbelifted,buildthemobile
basearoundit,asinstructedinAssembling Base
Around Machine on Page 6.
Lift heavy equipment carefully and with
the proper equipment. Get assistance is
if needed to reduce the risk of serious
personal injury.
Assembling Base
1. Mounteachswivelcastertoacornerbracketthat
has the four hole pattern and threaded posts using
(4)M8-1.25x16hexbolts,8mmflatwashers,8mm
lockwashers,andM8-1.25hexnuts,asshownin
Figure 5.
2. Mounteachfixedcastertoacornerbracketwiththe
eightholepatternusing(4)M8-1.25x16hexbolts,
8mmflatwashers,8mmlockwashers,andM8-1.25
hexnuts,asshowninFigure 6.
Orient the fixed casters so they point in the same
direction that your machine will typically be moved
(see Figure 7). Mounting the fixed casters in the
wrongdirectionwillmakeitdifficulttomoveyour
mobile base.
Note: Patience is required when installing the
fasteners inside the bottom of the fixed casters due
to space constraints.
Figure 5.Swivelcastermountedtocorner
bracket.
x 4x 4
OR
ThreadedPost
Figure 6. Options for mounting fixed
casters to eight hole pattern corner
brackets.
OR
x 4
Figure 7. Mounting casters based upon
typical direction of movement.
Kpg`ZXc;`i\Zk`fef]Dfm\d\ek
KFGM@<NF=:8JK<I
:FII<:K @E:FII<:K
x 4
