Shop fox D2260A - Assemble Base Frame

-4-
D2260A Mini Mobile Base Instructions
Figure 8.Cornerbracketswithcasters
layed out on floor.
Jn`m\c
:Xjk\ij
=ifek
=`o\[
:Xjk\ij
3. Laythefourcornerbracketsonthefloorinthe
pattern illustrated in Figure 8.
4. Makesurethecornerbracketswiththeswivel
casters are located on the side that will eventually
be the "front" and from which the machine will
typically be pushed.
Tip:Wipe a light coat of machine oil onto the top,
bottom, and sides of the rail ends before the next
step to make it easier to slide the rails into the
brackets and simplify later adjustments.
6. Adjust the assembly so the inside dimension of the
ModelD2260Afitsthefootprintofyourmachine,as
determined in Step 1 in Preparation on Page 2.
5. Slideeachsiderailinsideacornerbracket,making
sure the two long rails are parallel with one another
andthetwoshortrailsarealsoparallel,asshownin
Figure 9.
Note: The rails may look different depending upon
the configuration you have chosen.
—IfyouareattachingyourbasetotheModelD2259A
ShopFoxExtensionKit,refertotheinstructions
thatcamewithyourkit.
Note: Before continuing with the next step, you
will have to remove one of the rails on the Model
D2260A and replace it with the rail in the Model
D2259A kit with the rectangular mounting bracket
welded to it.
7. Makesureyoudonotextendthecornerbrackets
beyondthe"max"linemarkedontherails,as
shown in Figure 10.Extendingthebracketsbeyond
themaximumlinemayweakentherail-bracket
connections and damage the mobile base.
Figure 10. Maximum extension line on rail.
Figure 9.Siderailsinsertedintocorner
brackets(castersremovedforclarity).
Long Rail
ShortRails
Long Rail
SwivelCorner
FixedCorner
