Free Wheel Operation
The free wheel release lever (this may be red or yellow depending on the model of the scooter) is located inside the
Right or Left rear wheel. To disengage the motor, move the lever in the opposite direction – The scooter can now be pushed.
To re-engage the motor return the lever to the original location – The scooter should now be unable to be pushed.
WARNING!
Always re-engage the Free Wheeling device after use.
Failure to do so may result in Injury.
Do not release the free wheel lever on any incline.
Anti-Tip Wheels
The anti-tip wheels are located at the rear of the scooter frame. The anti-tip wheels are removable on some models. The
scooter should not be used unless the anti-tips are fitted.
Shoprider® is not responsible for the damage or injury due to improper or misuse of the scooter.
Circuit Breakers
Anti-Tip Wheels
Rear Chassis Cover
Free Wheel
Release Lever
Anti-Tip Wheels
Figure 13
16
