Technical Specifications
All specifications are subject to change without notice
1. Includes Anti tip wheels (Where fitted) Rocky 6 Golf – Golf bracket where fitted.
2. Driver weight may exceed weight of unit: speed must be reduced when turning.
3. Rocky 6 may be optioned with 330 x 100mm tyres.
DISCLAIMER
Congratulations on your purchase of the Shoprider® It is not intended to be used by individuals with physical limitations that
could prevent the user from operating this unit safely. Shoprider® disclaims all responsibility for any personal injury or
property damage, which may occur as a result of improper or unsafe use of its products. Mechanical or electrical defects will
be dealt with on a contingency liability basis.
SHOPRIDER Australia Pty Ltd
1 Business Way Malaga
Western Australia 6090
www.shoprider.com.au
Unit Specifications Rocky 6 Rocky 6 Golf 889SL 889ERSF 889ERS
Overall Dimensions
L x W x H (1) x 1300 x 1330 x 1120 x 1300 x 1170
Number Front 2 / 360mm 2 / 500mm 2 / 330mm 2 / 330mm 2 / 330mm
Size of Tyres (3) Rear 2 / 360mm 2 / 500mm 2 / 330mm 2 / 330mm 2 / 330mm
Maximum User Weight kg 227 227 136 159 136
(on flat level ground)
Total Weight
(with Batteries, kg 147 143 99 105 99
Basket & Seat)
Suggested Minimum amp 60 60 36 50 36
Battery Capacity
Charger 8amp 8amp 4amp 4amp 4amp
off board off board off board off board off board
Output of Motor W / Hp 1492 (2) 1492 (2) 890 (1.2) 1100 (1.50) 560 (0.75)
Maximum Speed (2) kph 15 12 12 12 8
up to on level ground
Maximum Climbing % “ 15, 9 15, 9 15,9 15,9 20,12
Angle @ (125kg) (125kg) (91kg) (113kg) (70kg)
Maximum weight shown
Turning Radius mm 1800 1800 1500 1450 1630
Suspension Y Y Y Y Y
MM 1430 x 680 1430 x 680 1300 x 640 1400 x 645 1340 x 600
