Shoremaster Infinity RS4 - Page 3

SHOREMASTER.COM | 3
PARTS & COMPONENTS
PARTS & COMPONENTS
*RS4 Bundle*
DESCRIPTION
PART NUMBER
QTY
ITEM
Frame 4 x 10100368718
Frame 4 x 4
10036951
(8)
Frame 4 x 1210036881
(8)
Frame 6 x 810038081
(8)
Foot Pad 100652329
Bolt Bag - Listed at Left
10044251
-
Infinity Dock Pocket
100659121 0
*1004425 - Bolt Bag - RS-4 Dock System*
DESCRIPTION
PART NUMBER
QTY
ITEM
T-Handle 3/8 x 1.5
100087621
Connector Clip
100465122
Nut 3/8 Brass
100180323
Bolt Carriage 3/8 X 1.0
100195624
Nut Flange 3/8
10018022
5
Blue Cap
100181526
Corner Cap
10008754
7
Infinity Dock System
RS4 Section
Part Numbers:
4 x 4 Section - 1004214
4 x 10 Section - 1005986
4 x 12 Section - 1005987
6 x 8 Section - 1005989
Decking Type 2' PANELS 1' PANELS
Cedar Wood Deck 1007557
Plain Aluminum Deck 1007546
Ipe Hardwood Deck 1007564
White Aluminum Deck 1007567
Tan Aluminum Deck 1003442
Tan Vertex Deck 1004074
Titan Deck 1024039 1021586
LEG POSTS
PART #
3' DOCK LEG POST (each) - 1003556
5' DOCK LEG POST (each) - 1000157
7' DOCK LEG POST (each) - 1000158
9' DOCK LEG POST (each) - 1000159
12' DOCK LEG POST (each) - 1000160
PARTS LIST "A"
PARTS LIST "B"
7
A
2
A
1
A
3
A
6
A
8
B
LEGS SOLD SEPERATELY
(CHOICE OF SIZE - 3', 5',
7', 9', AND 12')
4
A
5
A
10
B
9
B
