2.3 Contacts and useful addresses.
Information at:
• Shott International srl +39 049 9401150.
•
www.shott.it.
3 Product presentation.
3.1 Product scope.
These filters (product) are the most reliable nowadays in the market for the cleaning and the maintenance
of your domestic swimming pool. They find their application from children to professional’s aboveground
pools. Each model is provided of a multifunctional multifunctional valve that allows the application of the
product in many different ways. In particular the filters do not need special maintenance operations
because working directly on the multifunctional valve they allow their deep cleaning with no need of long
and exhausting operations.
3.2 Composition.
See Fig. 7.
# #
1
Multifunctional valve
5 Drain Tap
2
Soft O-ring for the sealing between the
multifunctional valve and the tank
6 Tank
3 Closing flange 7 Tube with body diffuser
4 Funnel 8 Finger
Tab. 1
Fig. 7
