TECHNICAL SPECIFICATIONS
Model Passive
CS-304B / CS-304W
System Type
Column Array Speaker
Input Voltage
70V/100V
Transformer selectable Power
5W /10W /20W / 40W
Power capacity (8Ω)
60W RMS, 120W Program
70V 1000Ω / 500Ω / 250Ω / 125Ω
100V 2000Ω / 1000Ω / 500Ω / 250Ω
Sensitivity (1w/1M)
93dB
Max SPL(1M)
114dB (calculated by 8ohms )
Frequency Response(-6dB)
180Hz-18KHz
Speaker
4×3" full range speaker,20mm Voice Coil
Angle of coverage(HxV)
90°x
20° @ 4 kHz
Connect
Phoenix
Enclosure Construction
Plywood cabiner,resistant paint,0.8mm metal grille
Suspension/Mounting
6×M8 Points For Mounting
Dimensions(H×W×D)
378mm(14.8")×98mm(3.9")×130mm(5.1")
Net weight
4.4KG/9.7Lbs
System Impedance
CS-308B / CS-308W
Column Array Speaker
70V/100V
7.5W /15W /30W / 60W
120W RMS, 240W Program
70V 667Ω / 333Ω / 167Ω / 83Ω
100V 1333Ω / 667Ω / 333Ω / 167Ω
95dB
119dB (calculated by 8ohms )
180Hz-18KHz
8×3" full range speaker,20mm Voice Coil
90°x 30° @ 4 kHz
Phoenix
Plywood cabiner,resistant paint,0.8mm metal grille
6×M8 Points For Mounting
730mm(28.8")×98mm(3.9")×130mm(5.1")
7.5KG/16.5Lbs
Model Passive
System Type
Input
Voltage
Transformer selectable Power
Power capacity (8Ω)
Sensitivity (1w/1M)
Max SPL(1M)
Frequency Response(-6dB)
Speaker
Angle of coverage(HxV)
Connect
Enclosure Construction
Suspension/Mounting
Dimensions(H×W×D)
Net weight
System Impedance
