2.3 Unscrew spark plug. Note: spark plug
gap should be set to 3-5mm.
3. Igniter Replacement
3.1 Undo the 5 mounting screws (29) and
remove right housing (15).
3.2 Undo contact screw (25) which retains
the cable (17,18) and the contact spring
(26)
3.3 Snap off the clamp (34) with a screw
driver.
