3.4 Pull out cable (9)
3.5 Untie and remove the ground strap (12)
3.6 Trigger/assembly (13) can now be lifted
out.
4. Orifice Replacement
IMPORTANT NOTE: The orifice (14) consists
of 6 slender, thin walled tubes which can
easily be bent or damaged if dropped or
mishandled. Once bent, the performance of
the gun can be seriously impaired. For this
reason the following operation should be
performed with utmost care.
