4 / 27
01
02
13
14
14
13
B
B
18
18
14
18
Step 3:
Set console (#3) into main frame (#2), and connect C of main frame with C of console. Use Allen Wrench (as
shown in figure) to fix console into #15 and #19. Screw it tight after 4 screws are screwed.
Notice: When setting main frame, it needs 2 persons to operate, avoiding connector caught. When connecting,
please note the direction of BNC and do not pull the wire hard.
15
19
03
C
C
02
16
16
