SPECIFICATIONS
PSM1000
RF Carrier Range
470–952 MHz
varies by region
Compatible Frequencies
Per band
39
Tuning Bandwidth
72–80 MHz
Note: varies by region
Operating Range
environment dependent
90 m (300 ft)
Audio Frequency Response
35 Hz–15 kHz +/-1dB
Signal-To-Noise Ratio
A-Weighted
90 dB (typical)
Total Harmonic Distortion
ref. ±34 kHz deviation @1 kHz
<0.5% (typical)
Companding Patented Shure Audio Reference Companding
Spurious Rejection
ref. 12dB SINAD
>80 dB (typical)
Frequency Stability
±2.5 ppm
MPX Pilot Tone
19 kHz (±0.3 kHz)
Modulation FM*, MPX Stereo
*ref. ±34 kHz deviation @1 kHz
Operating Temperature -18°C to +57°C
P10R
Tri-Band RF Filtering –3 dB at 30.5 MHz from the center frequency of
each band
Active RF Gain Control
31 dB
Adjusts RF sensitivity to provide more RF dy-
namic range
Active RF Sensitivity
at 20 dB SINAD
2.2 µV
Image Rejection
>90 dB
Adjacent Channel Rejection
>70 dB
Squelch Threshold
22 dB SINAD (±3 dB)
default setting
Intermodulation Attenuation
>70 dB
Blocking
>80 dB
Audio Output Power
1kHz @ <1% distortion, peak power,
@32Ω
100 mW (per output)
Minimum Load Impedance
9.5 Ω
High Boost
Selectable: +2 dB, +4 dB @ 10 kHz
Volume Limiter Selectable: 3–9
Limits volume adjustment knob. Selected value
analogous to volume knob increment.
Net Weight
196 g(6.6) (with batteries)
Dimensions
99 x 66 x 23 mm (3.9 in. x 2.6 in. x 0.9 in.) H
x W x D
Battery Life
4–6 hours (continuous use) AA batteries
P10T
RF Output Power
selectable: 10, 50, 100 mW (+20 dBm)
RF Output Impedance
50 Ω (typical)
Net Weight
4.5 kg (10)
Dimensions
44 x 483 x 343 mm (1.7 x 19.0 x 13.5 in.),
H x W x D
Power Requirement Input:
100–240 V AC, 50/60 Hz, 0.5
Amax. (5.5, with outlet loaded)
Output:
100–240 V AC, 50/60 Hz, 5
Amax., unswitched
Audio Input
Connector Type
Combination XLR and 6.35 mm (1/4") TRS
Polarity XLR: Non-inverting (pin 2 positive
with respect to pin 3)
6.35 mm
(1/4") TRS:
Tip positive with respect
to ring
Configuration Electronically balanced
Impedance
70.2 kΩ (actual)
Nominal Input Level
switchable: +4 dBu, –10dBV
Maximum Input Level +4 dBu:
+29.2 dBu
-10dBV:
+12.2 dBu
Pin Assignments XLR: 1=ground, 2=hot, 3=cold
6.35 mm
(1/4") TRS:
Tip=hot, Ring=cold,
Sleeve=ground
Phantom Power Protection
Up to 60 V DC
Audio Output
Connector Type 6.35 mm (1/4") TRS
Configuration Electronically balanced
Impedance Connected directly to inputs
