Shure SM7B - Page 10

Shure Incorporated
10/13
Output Impedance
150Ω
Sensitivity
(@ 1 kHz, open circuit voltage)
59dBV/Pa[1](1.12mV)
Hum Pickup
(typical, at 60 Hz, equivalent SPL/mOe)
11dB
Polarity
Positive pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3
Net Weight
0.764kg(1.69lbs)
Housing
Dark gray enamel aluminum and steel case with dark gray foam windscreen.
[1] 1 Pa=94 dB SPL
Typical Frequency Response
