Transmitter Specifications
T2, UT2 Hand-Held Transmitter
RF Output UT2 15 mW Typical
T2 50 mW Typical (FCC); 20 mW Typical (ETSI)
Dimensions UT2/58 (SM58) 241 mm H x 51 mm D (9.49” H x 2.01” D)
UT2/BETA58 241.3 mm H x 36.83 mm D (9.5” H x 1.45” D)
UT2/PG58 227 mm H x 51 mm D (8.94” H x 2.01” D)
T2/58 (SM58) 236 mm H x 51 mm D (9.29” H x 2.01” D)
T2/PG58 222 mm H x 51 mm D (8.74” H x 2.01” D)
Net Weight UT2/58 (SM58) 296g (10.4 oz.)
UT2/BETA58 296g (10.4 oz.)
UT2/PG58 267 g (9.4 oz.)
T2/58 (SM58) 295 g (10.4 oz.)
T2/PG58 266 g (9.4 oz.)
Power Requirements 9 V alkaline battery (Duracell MN1604 recommended); 9 V lithium ULTRALIFE
battery optional.
Nominal Current Drain UT2 40 mA
T2 30 mA
Shure Model T2 and UT2 Transmitters meet the essential requirements of the European R&TTE Directive 99/5/EC and are eligible to carry the CE
marking.
T2/58: Type accepted under FCC Parts 74 and 90. Certified by IC in Canada under TRC-78.
UT2/58, UT2/BETA58: Type accepted under FCC Part 74. Certified by IC in Canada under RSS-123.
T1, T1G, T11, UT1 Body-Pack Transmitter
RF Output T1, T1G 50 mW typical
T11 20 mW typical
UT1 15 mW Typical
Input Configuration Unbalanced
Connector Type T1, T11, UT1 4–pin Miniature connector (male)
T1G 1/4”
Actual Impedance 1 MΩ
Connector Pin Assignments T1, T11, UT1 Pin 1: ground • Pin 2: +5 V bias • Pin 3: audio • Pin 4: 20kΩ resistor to audio ground
T1G Tip: audio • Sleeve: ground
Dimensions T1, T1G 64 mm H x 106 mm W x 24 mm D (2.52” H x 4.17” W x 0.95” D)
T11, UT1 83 mm H x 64 mm W x 26 mm D (3.27” H x 2.50” W x 1.03” D)
Net Weight T1, T1G 96.4 g (3.4 oz.)
T11, UT1 79.4g (2.8 oz.)
Power Requirements 9 V alkaline battery (Duracell MN1604 recommended); 9 V lithium ULTRALIFE
battery optional.
Nominal Current Drain T1, T1G, T11 30 mA
UT1 40 mA
Shure Model T11 and UT1 Transmitters meet the essential requirements of the European R&TTE Directive 99/5/EC and are eligible to carry the CE
marking.
T1, T1G: Type accepted under FCC Parts 74 and 90. Certified by IC in Canada under TRC-78.
UT1: Type accepted under FCC Part 74. Certified by IC in Canada under RSS-123.
