Shure UA874 - Specifications and Certifications; Technical Specifications; Certifications and Compliance; Optional Accessories

15.35 in
14.33 in
390 mm
364 mm
5
Certifications
This product meets the Essential Requirements of all relevant European
directives and is eligible for CE marking.
The CE Declaration of Conformity can be obtained from: www.shure.com/
europe/compliance
Authorized European representative:
Shure Europe GmbH
Headquarters Europe, Middle East & Africa
Department: EMEA Approval
Jakob-Dieffenbacher-Str. 12
75031 Eppingen, Germany
Phone: 49-7262-92 49 0
Fax: 49-7262-92 49 11 4
Email: EMEAsupport@shure.de
Specifications
Connector Type
BNC, Female
Impedance
50 Ω
Power Requirements
10 to 15 V DC bias from coaxial connection, 75 mA
RF Frequency Range
UA874US
470–698 MHz
UA874E
470–790 MHz
UA874WB
470–900 MHz
UA874X
925–952 MHz
Reception Pattern
3 dB Beam Width
70 degrees
Third-order Overload Intercept Point (OIP3)
>30 dBm
Antenna Gain
On Axis
7.5dBi
Signal Gain
±1 dB, Switchable
+12 dB
+6 dB
0 dB
−6 dB
RF Overload LED Threshold
−5 dBm
RF overload LED does not operate for passive gain settings
Dimensions
UA874
316 x 359 x 36 mm (H x W x D)
UA874X
224 x 234 x 36 mm (H x W x D)
Weight
UA874
317 g (11.2 oz.)
UA874X
213 g (7.5 oz.)
Operating Temperature Range
−18°C (0°F) to 63°C (145°F)
Storage Temperature Range
−29°C (-20°F) to 74°C (165°F)
Optional Accessories
Protective zipper pouch
WA874ZP
