Shure WL183 - Specifications; Sensitivity; Maximum SPL; Self Noise (A-Weighted)

Shure Incorporated
6/8
CARDIOID (WL185)
Specifications
Type
Condenser (electret bias)
Frequency Response
50 to 17,000 Hz
Output Impedance
1800 Ω
Sensitivity
WL183 -40.0 dBV/Pa
WL184 -44.5 dBV/Pa
WL185 -45.5 dBV/Pa
Maximum SPL
WL183 125.0 dBSPL
WL184 129.5 dBSPL
WL185 130.5 dBSPL
Self Noise (A-Weighted):
WL183 22.5 dBSPL
WL184 27.0 dBSPL
WL185 28.0 dBSPL
[1]
