The table below shows brix pump ratios currently available. The brix pump is shipped with the 3-way
sanitizing valve.
Model Ratio Qty./Box
94-260-01 3:1 pump 8
94-260-03 4:1 pump 8
94-260-05 5:1pump 8
94-260-06 5.3:1 pump (6:1 APR FOR FCB) 8
94-260-07 7.7:1 pump 8
94-260-17 4.2:1 pump w/o sold out feature 8
Technical Specs
DESIGN: Positive Displacement; Fix Ratio (non-adjustable)
POWER SOURCE: Potable Water
MATERIALS OF
CONSTRUCTION:
Acetal Copolymer, EPDM, Santoprene, Silicone, 316 Stainless Steel-FDA sanctioned,
NSF listed
TEMPERATURE LIMITS:
34 - 120°F [2-45°C]
DIMENSIONS 7.6" x 5.2" x 5.7" [19.3 x 13.2 x 14.47 cm]
WEIGHT: 2.2 lbs. [1 kgs]
OPERATING PRESSURE: 50 PSI. [3.4 bar] MAX. / 25 PSI. [1.7 bar] MIN.
ACCURACY: ± 3% of available ratio
SOLD OUT: Automatic B-I-B Vacuum Shut-off @ 18-22 in. Hg. [48-61 kPa]
AVAILABLE FITTINGS:
3/8" [10mm] Barb, Plastic 90° Std. Configuration,
1/4" [6mm] , 3/8" [10mm], and 1/2" [13mm] barb, Pla
Straight and/or 90° configurations
